The Agilent/Keysight 8595EM EMC Analyzer is a stand-alone instrument for electromagnetic compatibility testing and pre-compliance diagnostics across 9 kHz to 6.5 GHz. It combines EMI analysis with full-spectrum analysis capabilities, eliminating the need for external computing infrastructure. Purpose-built for automated EMC precompliance measurement, the analyzer delivers rapid signal detection, storage, and regulatory compliance assessment without operator intervention.
– Technical Specifications
Frequency & Performance
• Operating range: 9 kHz to 6.5 GHz
• Suitable for precompliance testing of products with clock frequencies up to 1 GHz
• Maximum input: +30 dBm average continuous power (1 W); +50 dBm peak pulse power (<10 µs pulse width, 10 MHz
Power Requirements
• Operating voltage: 90 to 132 Vrms, 47 to 440 Hz; or 195 to 250 Vrms, 47 to 66 Hz
• Power consumption: <500 VA; <180 W
Physical Characteristics
• Dimensions: 325 mm W × 163 mm H × 427 mm D (without handle, feet, or cover)
• Weight: 16.4 kg
• Operating temperature: 0°C to +55°C
• Storage temperature: –40°C to +75°C
• Audible noise: <37.5 dBA, <5.0 Bels power (ISO 7779)
– Key Features
• CISPR band presets with linked video and resolution bandwidths
• Built-in amplitude correction for antenna, amplifier, and cable losses
• Simultaneous limit-line display comparing signals against up to two regulatory limits plus user-specified measurement margins
• Automated routines measuring all signals across specified frequency ranges
• Signal storage and reporting for up to 239 signals
• Internal cardcage accommodating up to four plug-in circuit card options
• Downloadable, application-specific measurement personalities
• EMI compatibility per CISPR Pub. 11 and Messempfaenger Postverfuegung 526/527/79
– Interfaces
• GPIB, RS-232, and Parallel Printer Interface (optional)
– Compatibility & Integration
Built on the Agilent 8590 E-series spectrum analyzer platform. Supports optional circuit cards and application-specific measurement personalities for RF Wireless Communications, Cable TV, and EM applications.
