Bluetest RC800 Reverberation Test Chamber

The Bluetest RC800 is a reverberation chamber designed for efficient Over-The-Air (OTA) testing of wireless devices, providing a controlled RF environment to minimize external interference and ensure repeatable measurements. It is particularly suited for MIMO and throughput testing, offering a cost-effective solution for wireless performance verification. The system utilizes Bluetest’s patented reverberation chamber technology, which simulates real-world multipath environments to evaluate wireless device performance rapidly. The RC800 is part of a broader range of Bluetest Reverberation Test Systems (RTS) that cater to various device sizes and testing requirements, from small IoT devices to large base stations. The system is operated using the Bluetest Flow software platform, which streamlines test setup, execution, and data analysis.

### Technical Specifications

* **Product Name:** Bluetest RC800
* **Product Type:** Reverberation Chamber for OTA Testing
* **Primary Function:** Efficient Over-The-Air (OTA) testing of wireless devices, including MIMO and throughput testing.
* **RF Environment:** Controlled RF environment to minimize external interference and ensure repeatable measurements.
* **Measurement Capabilities:**
* Total Radiated Power (TRP)
* Total Isotropic Sensitivity (TIS)
* Data Throughput (TPUT)
* Antenna Efficiency
* Diversity Gain
* MIMO Capacity
* Radiated Power Measurements
* Input Impedance Measurements
* RF Performance Validation
* Wireless Performance Verification [cite: short description]
* **Field Stirring Mechanism:**
* 2 Mechanical Stirrers
* Platform Stirrer
* Polarization Stirring
* 25 MHz Frequency Stirring
* **Supported Wireless Standards:**
* Bluetooth
* Wi-Fi (including Wi-Fi 6/7)
* ZigBee
* GSM
* UMTS
* LTE
* 5G NR (including Standalone and Non-Standalone)
* IEEE 802.11 a/b/g/n/ac/ax/be (Wi-Fi 7)
* CDMA
* CDMA 1xRTT DATA
* CDMA 1xEV-DO
* GPRS
* EGPRS
* 5G RedCap
* **Frequency Range:** Specific frequency range for the RC800 is not detailed in the provided search results, but Bluetest chambers generally cover frequencies from 400 MHz up to 67 GHz, with specific models having defined ranges such as 2.4-7.125 GHz for RTS25 and up to 50 GHz or 67 GHz for other models.
* **Software Platform:** Bluetest Flow
* **Flow Manager:** Visual configuration of test setups with drag-and-drop instruments, cables, and chambers; supports nested loops, batch measurements, remote control, and live monitoring.
* **Flow Touch:** Responsive web interface for control via desktop, tablet, or smartphone, including built-in chamber touchscreen.
* **Flow Analyzer:** Tool for searching, plotting, and comparing results; organizing results, adding tags, combining campaigns, and exporting HTML reports.
* **Power Tools & Automation:** Enables creation of complex, multi-tech test sequences; supports on-the-fly data processing via custom scripts.
* **Integration Capabilities:** Supports integration with instruments from Rohde & Schwarz, Anritsu, and Keysight; features an open API for pushing measurement data into Python, MATLAB, or cloud dashboards.
* **Measurement Speed:** Measurements can be up to 10 times faster than traditional methods in anechoic chambers. Typical test times are reported as:
* Passive Antenna Measurements: 1 min
* Passive Diversity Gain: 1 min
* Passive MIMO Capacity: 1 min
* TRP (Total Radiated Power): 1 min/channel
* TIS (Total Isotropic Sensitivity): 10 min/channel
* TPUT (Throughput) Measurement: 1-2 min

### Physical Characteristics

* **Test Volume:** Specific dimensions for the RC800 are not explicitly stated in the provided search results. However, other Bluetest models have defined test volumes:
* RTS25: 40x30x30 cm
* RTS65: 50x50x50 cm
* RTS85/RTS95B: 1.5 x 1.5 x 2 m
* **DUT Size:** The RC800 is designed for efficient OTA testing of wireless devices. The appropriate DUT size would depend on the specific configuration and potentially the model series it belongs to. General DUT size capabilities range from small devices (like IoT tags) to large devices (like TVs or base stations) across the Bluetest RTS product line.
* **DUT Weight:** Specific maximum DUT weight for the RC800 is not detailed. However, other Bluetest models support varying DUT weights:
* RTS25: 12 kg
* RTS65: 20 kg
* RTS85HP: 100 kg on pole mount
* RTS85/RTS95B: 150 kg, with a 200 kg option available for RTS95B

### Interfaces

* **Antenna Ports:** The number and type of antenna ports can vary by model. For example, the RTS65 supports 4-16 SMA ports + 2 mmWave ports, while the RTS25 has 4 or 8 N-type ports. Specifics for the RC800 are not provided.
* **RF Interfaces:** Easily accessible RF interfaces are a feature of newer Bluetest chambers.
* **DUT Interfaces:** Multiple DUT interface options are available for power and device communication/control.
* **Connectivity:** Supports remote control via touchscreen interfaces. The Bluetest Flow software allows for integration with external test equipment and custom scripting.

### Compatibility

* **Test Scenarios:** Ideal for MIMO and throughput testing, validating wireless performance in controlled RF environments that simulate real-world multipath conditions [cite: short description, 1, 5, 8].
* **Device Types:** Suitable for a wide range of wireless devices, including:
* Smartphones
* Tablets
* IoT devices (e.g., WLAN, Bluetooth, ZigBee)
* Laptops
* Base Stations
* Large form factor devices (e.g., TVs, connected appliances)
* Wearables
* Automotive systems (infotainment, V2X, sensor systems)
* Medical devices and IoMT
* Tactical radios and drones
* **Integration with Test Equipment:** Designed for integration with signaling testers such as the Rohde & Schwarz CMX500 OBT for 4G, 5G NR, and WLAN testing. Also collaborates with Anritsu and Keysight.
* **Standards Compliance:** Supports Over-The-Air (OTA) testing according to CTIA and 3GPP standards.
