Kimmon IK Series He-Cd Laser Model IK3083R-DB Calibrated

The Kimmon IK Series IK3083R-DB is a calibrated Helium-Cadmium gas laser delivering stable, coherent UV light at 325 nm for scientific and industrial measurement, inspection, and materials processing. This Class 3B continuous-wave system generates 10 mW of output power in a diffraction-limited TEM00 mode with exceptional beam quality and pointing stability.

– Technical Specifications

Optical Performance
• Wavelength: 325 nm (UV)
• Output Power (CW): 10 mW
• Transverse Mode: TEM00
• Polarization: Linear, > 500:1 ratio
• Beam Diameter (1/e²): < 1.0 mm at 100 mm from output coupler
• Beam Divergence: < 0.4 mrad
• Beam Pointing Stability: ±25 μrad (at 25°C constant temperature)
• Power Stability: ±2% over 4 hours at 25°C; < 20% across 10–40°C operating range
• RMS Noise: 2.0% RMS; 500:1 ratio enables compatibility with polarization-sensitive instrumentation. Tight beam pointing stability of ±25 μrad supports long-distance alignment in metrology and interferometric systems. Helium-cadmium gas discharge provides exceptional wavelength stability essential for spectroscopy and calibration work.

– Typical Applications

Photoluminescence, Raman spectroscopy, flow cytometry, fluorescence imaging, semiconductor inspection, holography, lithography, photopolymer exposure, interferometry, defect inspection, precision measurement, and materials processing.

– Compatibility & Integration

Laser head and power supply integrate via internal control circuit board, enabling straightforward head replacement. Power supply model KP2014C is compatible with this He-Cd system. Operating temperature: 10–40°C; Storage: -10 to 50°C.
