3Com Baseline 3C16477A

The 3Com Baseline Switch 3C16477A is a 1U rack-mountable, web-managed Layer 2 Ethernet switch engineered for small to mid-sized network deployments. This 24-port configuration combines 10/100 Mbps Fast Ethernet ports with dual-purpose Gigabit uplinks supporting both copper (10/100/1000BASE-T) and SFP fiber connectivity. The switch delivers non-blocking, wirespeed switching with an 8,192-entry MAC address table and supports up to 512 port-based VLANs per IEEE 802.1q standards. Link aggregation enables manual grouping of up to 8 ports across 6 trunks for increased bandwidth.

– Technical Specifications

• Switching Method: Store-and-forward
• MAC Address Table: 8,192 entries
• VLAN Support: 512 port-based VLANs (IEEE 802.1q)
• Link Aggregation: 6 trunks, maximum 8 ports per trunk
• Console Port, Stacking Port, and USB Port: All present
• Power Consumption: 28 W maximum
• Heat Output: 96 BTU/hr maximum
• Input Voltage: 100–240 VAC, 50/60 Hz
• Dimensions: 17.3 in. (W) × 6.8 in. (D) × 1.7 in. (H)
• Weight: 3.1 lbs (1.5 kg)

– Key Features

• Twenty-four auto-negotiating 10/100 Mbps RJ-45 ports
• Two dual-purpose Gigabit uplink ports (copper or SFP transceiver compatible)
• SFP slot support for flexible fiber-optic deployment
• SNMP-based management
• Auto-voice VLAN support for converged voice/data networks
• IGMP snooping and query for multicast traffic control
• IEEE 802.1X network authentication capability
• LED indicators for power, link status/speed, and duplex mode

– Typical Applications

• Enterprise branch office and departmental LAN switching
• Voice-over-IP network backbone segments
• Cost-effective managed access switching for mid-market organizations

– Compatibility & Integration

Web-based management interface with SNMP support enables remote monitoring and configuration. Dual Gigabit uplinks provide flexible scaling—copper ports for short-reach connectivity or SFP transceivers for extended fiber runs.
