The 8020-ILC-S Interlock Expansion Termination Plug is a connector accessory designed to terminate the INTERLOCK EXPANSION port on the Tektronix Model 8020 High Power Interface Panel. This termination plug preserves interlock system integrity in both single-unit and daisy-chained multi-unit configurations.
For standalone Model 8020 operation, install the plug directly into the INTERLOCK EXPANSION port on the device side of the panel. In daisy-chain setups with multiple Model 8020 units, the plug terminates the INTERLOCK EXPANSION port of the final unit in the series. Proper termination prevents signal reflections and maintains reliable interlock operation across the system.
– Technical Specifications
• Model Number: 8020-ILC-S
• Function: Interlock Expansion Termination Plug
• Pinout Configuration: Pin 2 shorted to Pin 4
– Key Features
• Termination connector for INTERLOCK EXPANSION port
• Maintains signal integrity in single and cascaded configurations
• Simple installation design for device-side panel mounting
• Fixed pinout topology optimized for interlock circuit protection
– Typical Applications
• Single Model 8020 High Power Interface Panel installations
• Final-unit termination in multi-unit daisy-chain configurations
• Interlock system expansion port closure and signal conditioning
– Compatibility & Integration
• Compatible with: Tektronix Model 8020 High Power Interface Panel
• Interface: INTERLOCK EXPANSION port connector
• Installation: Device-side panel mounting (single unit) or final-unit chain termination (multi-unit)
