The Abaco Systems / Condor Engineering QVME-1553-1SA is a single-channel MIL-STD-1553 VMEbus interface board engineered for avionics and defense applications requiring high-performance military databus communication. It operates as a fully compliant MIL-STD-1553A and B Notice II interface, supporting Bus Controller (BC), Remote Terminal (RT), and Bus Monitor (BM) modes in multi-function or single-function configurations. The board delivers 1 Mbyte of RAM per channel with dual-redundant architecture and flexible coupling options—transformer or direct—to accommodate diverse system integration requirements.
– Technical Specifications
• Interface: VMEbus
• Standard Compliance: MIL-STD-1553A and B Notice II
• Channels: 1 (dual-redundant)
• Memory: 1 Mbyte RAM per channel
• Message Time-Tagging: 45-bit
• Coupling Options: Selectable transformer or direct coupling
• Variable Voltage Support: Optional
– Key Features
• Multi-function operation: simultaneous BC, up to 31 RTs, and BM capability
• Single-function modes: BC, RT, or BM operation
• Extensive BC and RT link-list structures for complex mission profiles
• Automatic and manual RT Status Bit and Mode Code responses
• RT Map Monitoring and IRIG/GPS synchronization capabilities
• Advanced error detection, injection, and detailed reporting
• Avionics-level discretes support
• MIL-STD-1760 start-up-time compliance
• Message trigger support
– Software & Integration
• Advanced API software reduces development cycle time
• Supported operating systems: Windows, VxWorks, LynxOS, Linux, NT, 98, 95, 3.1, DOS, Integrity
• BusTools/1553 bus analysis software available
– Environmental Specifications
• Commercial: 0 to +70°C
• Extended/Industrial: −40°C to +85°C
• Humidity: Up to 90% relative humidity (non-condensing)
• Available Versions: Commercial, industrial, conductively cooled
• Conformal Coating: Optional
– Compatibility & Integration
Fully compatible with VMEbus systems and compliant with MIL-STD-1553A/B Notice II standards.
