Abaco Systems / SBS / Greenspring IP-16DAC IndustryPack Module

The Abaco Systems / SBS / Greenspring IP-16DAC is an IndustryPack module designed for digital-to-analog conversion. This module offers 16 channels of 16-bit resolution, making it suitable for applications requiring precise analog output generation. Its design prioritizes channel density and high-fidelity analog performance.

### Technical Specifications

* **Product Family:** IndustryPack Module
* **Manufacturer:** Abaco Systems / SBS / Greenspring
* **Model:** IP-16DAC
* **Number of Channels:** 16-channel DAC
* **Resolution:** 16-bit
* **DAC Type:** Crystal Semiconductor CS4333 stereo DACs are utilized in some variants, offering 16-bit resolution in 2’s complement format.
* **Audio Quality Performance:** The CS4333 DACs are designed with high-fidelity audio applications in mind, specifying 94 dB dynamic range, 0.003% THD, 1-bit D/A conversion, and ultra-linear analog low-pass filtering.
* **Analog Output Stage:** Features RF filtered analog power, an isolated analog ground plane, and optimized analog stages through careful layout.
* **Operational Amplifiers:** Linear Technology LT1114 precision picoamp input Op Amps are used, contributing to uniform, low-drift analog output.
* **Configuration:** Software-configurable as master or slave for multi-IP synchronization.
* **Synchronization:** Multiple IP-DAC SU modules can be ganged and updated simultaneously via an RS-485 sync signal, allowing for up to 33 IPs (528 channels) to be updated concurrently.
* **Output Level Shifting and Offset Correction:** User-programmable via a separate DAC channel.
* **Type:** Type II IndustryPack module.
* **Component Density:** Utilizes low-profile surface-mounted components on both sides for maximum channel/slot density.
* **Alternative Versions:** An 8-channel Type I version is also available.
* **Digital Voltage Readability:** DAC registers are readable by software.
* **DAC Clearing:** DACs can be cleared by software or reset to bipolar or unipolar zero.
* **External Power Supplies:** Option to use external power supplies to minimize system noise.
* **De-glitching Hardware:** Internal de-glitching hardware included for faster settling times.
* **Calibration:** Factory calibration and low drift contribute to high accuracy and repeatability.
* **Output Ranges:** Four output ranges are available, including bipolar and unipolar configurations.
* **Remote Sense:** Feature available for direct interface to target hardware.
* **Drift Specification:** For applications requiring higher stability, the IP-16DAC is recommended for its 3 ppm/°C drift.

### Electrical Specifications

* **Resolution:** 16-bit DAC
* **Input Format:** 2’s complement
* **Dynamic Range:** 94 dB (specified by Crystal Semiconductor CS4333)
* **Total Harmonic Distortion (THD):** 0.003% (specified by Crystal Semiconductor CS4333)
* **D/A Conversion:** 1-bit conversion

### Interfaces

* **IndustryPack Interface:** Compliant with IndustryPack standards.
* **Synchronization Signal:** RS-485 sync signal for ganging multiple modules.

### Physical Specifications

* **Form Factor:** Single-wide IndustryPack module.
* **Component Placement:** Low-profile surface-mounted components on both sides of the PCB.

### Compatibility

* **IndustryPack Carrier Boards:** Designed to interface with IndustryPack carrier boards.
* **Synchronization:** Capable of being ganged with other IP-DAC SU modules for simultaneous updates.

### Applications

The Abaco Systems / SBS / Greenspring IP-16DAC module is suitable for a variety of demanding applications, including:
* Instrumentation
* Precision positioning systems
* Calibration equipment
* Remote programming applications
* High-fidelity audio applications

Why Choose Aumictech for Abaco Systems / SBS / Greenspring IP-16DAC?
At Aumictech, we specialize in supplying high-end embedded computing and I/O solutions. Whether you need precise 16-channel digital-to-analog conversion, high-fidelity audio output capabilities, or a versatile module for instrumentation and control applications, our team ensures the Abaco Systems / SBS / Greenspring IP-16DAC delivers maximum performance for your application.
