Abaco Systems / SBS / Greenspring IP-UNIDIG-BUF 24 Differential I/O IndustryPack Module

The Abaco Systems / SBS / Greenspring IP-UNIDIG-BUF is a single-wide IndustryPack module designed to provide 24 digital input/output (I/O) channels. This module is engineered for robust industrial applications, offering versatile digital I/O capabilities. Each of the 24 lines can be individually and dynamically configured as either an input or an output, providing significant flexibility for various system integrations. The module supports double-buffered inputs and outputs, which is particularly beneficial for simulation systems that require simultaneous latching of numerous I/O signals.

### Technical Specifications

* **Form Factor:** Single-wide Type I IndustryPack
* **IndustryPack Interface:** Complies with ANSI/VITA-4
* **Interface Speed:** 8 MHz
* **Wait States:** None
* **Number of Digital Lines:** 24 individually programmable input or output lines
* **Input Characteristics:**
* Voltage Range: +15 V to -5 V
* Logic Threshold: 1.25 V with 50 mV hysteresis
* Direct compatibility with CMOS/TTL
* **Output Characteristics:**
* Driver Type: Open collector transistor with 1 kOhm pullup
* Continuous Load Current: Sinks up to 64 mA
* Output Voltage (Vol): 0.80 V at 64 mA Ic
* **Buffering:** Double-buffered input and output capability
* **Configuration:** Each line is dynamically and individually configurable as input or output
* **Clocking:** Cascadable external clock triggers double-buffering. A bit in the Control Register allows selection of clock polarity for latching on rising or falling edges. Can function in Master/Slave mode for synchronizing multiple IndustryPacks.
* **Reset:** Resets the open collector output driver and disables double buffering for a consistent software interface.
* **ESD Protection:** None
* **Interrupts:** None

### Electrical Specifications

* **Power Requirements (No Load):** +5 VDC, 510 mA typical

### Physical Specifications

* **Dimensions:** 1.8 inches x 3.9 inches
* **Weight:** 0.06 kg (0.1 lb)

### Environmental Specifications

* **Operating Temperature:** 0°C to +70°C
* **Storage Temperature:** –40°C to +85°C
* **Humidity:** 5% to 95% non-condensing

### Compatibility and Software

* **Compatibility:** IndustryPack compatible. Complies with ANSI/VITA-4.
* **Software:** A subroutine library and Windows NT drivers are available. Engineering kits include relevant datasheets for components such as Motorola MMPQ2369 and AMD AM26LS33SC.

### Related Products and Engineering Kits

* **Engineering Kits:**
* EKIP50-UNIDIG: For carriers with 50-pin ribbon cable header front panel I/O connectors. Includes a 6-foot 50-conductor ribbon cable and screw terminal blocks.
* EKHD50-UNIDIG: For carriers with HD50 front panel I/O connectors. Includes a 6-foot HD50 male to HD50 male cable and screw terminal blocks.
* EKCM50-UNIDIG: For carriers with Champ50 front panel I/O connectors. Includes a 6-foot Champ50 male to HD50 male cable and screw terminal blocks.
* All engineering kits include user manuals, bill of materials, schematics, and assembly diagrams.
* **Software:**
* QP-UNIDIG-DIG: QuickPack subroutine library for IP-Unidig, containing C source code and release notes.
* ND-SDPACK: Windows NT 4.0 SDpacK IndustryPack driver CD-ROM.
* **Associated Products:** IP-UNIDIG-I (IndustryPack with 24 differential I/O lines).
