Abaco Systems / SBS / Greenspring VIPC618 IndustryPack Carrier

The Abaco Systems VIPC618 is a 6U VMEbus IndustryPack carrier designed to integrate IndustryPack (IP) modules into VMEbus systems. It provides the necessary mechanical and electrical interface for these modules, supporting four single-wide or up to two double-wide IndustryPacks. This carrier facilitates the integration of various I/O, ID, memory, and interrupt functions from the IP modules into the VMEbus environment.

### Technical Specifications

* **Form Factor:** 6U VMEbus
* **IndustryPack Slots:**
* Supports 4 single-wide IndustryPacks
* Supports up to 2 double-wide IndustryPacks
* **VMEbus Interface:**
* Occupies 1024 contiguous bytes in the VMEbus short I/O (A16/D16) space
* Carrier base address is configurable via shunt groups E3 and E7
* Select signals generated by comparing VMEbus address lines with shunt group values
* Supports user and supervisor accesses, as well as read-modify-write operations
* Conforms to VMEbus Specification C.1 (IEEE P1014/D1.2 and IEC 821 bus)
* **IndustryPack Interface:**
* Logic Interface conforms to ANSI/VITA 4-1995
* Each IP module has an I/O space of 128 bytes and an ID PROM space occupying adjacent 128 bytes
* I/O spaces start on offsets of 256 bytes from the carrier base address
* Supports 8 MHz operation only
* 32-bit interface and IndustryPack DMA are not supported
* Memory is mapped into either A24 or A32 space, supporting up to 8 MB of memory per IP slot
* **I/O Connectors:**
* Front-panel I/O through high-density shielded 50-pin subminiature D connectors (AMP LIMITE 0.050 series, AMP part number 749831-5)
* These connectors include latches for reliable connections in vibration environments
* Offer significant reduction of EMI emissions
* 64 lines of back-panel I/O via P2 (all 50 I/O pins from slot D and a configurable selection of 14 pins from slot C)
* **Power:**
* Provides fuse protection, RF filtering, and de-coupling capacitance on all IP power lines
* **Interrupts:**
* IndustryPack interrupts mapped 1:1 to VME IRQ levels by shunt or PLD selections
* The standard VIPC618 maps each IndustryPack interrupt line to a single VMEbus interrupt level
* Versions with custom PLD programming may be ordered with custom interrupt mappings
* Supports two interrupt channels per IP module
* **Memory:**
* Up to 8 MB of memory per slot

### Physical Characteristics

* **Form Factor:** 6U VMEbus
* **Connectors:**
* High-density shielded 50-pin subminiature D connectors for front-panel I/O
* VMEbus P2 connector for back-panel I/O

### Compatibility

* **VMEbus:** Conforms to VMEbus Specification C.1
* **IndustryPack:** Conforms to the IndustryPack Logic Interface ANSI/VITA 4-1995
* **IP Module Size:** Supports single-wide and double-wide IndustryPacks
* **IP Module Clock Speeds:** Supports 8 MHz operation only
* **32-bit Operation:** 32-bit interface and IndustryPack DMA are not supported

### Environmental Considerations

* **EMI Emissions:** High-density shielded I/O connectors significantly reduce EMI emissions
* **Vibration:** Latched connectors offer highly reliable cable connections in severe vibration environments

### Notes on Product Status

The Abaco Systems VIPC618 entered a Restricted Production Phase (RPP) on March 30, 2005. Documentation and software may be available in the downloads section for this product.
