Abaco Systems / VMIC VMIVME-2232-110 32-Channel Relay Output Board with Built-in-Test (BIT)

The Abaco Systems / VMIC VMIVME-2232-110 is a 32-channel relay output board for VMEbus systems with integrated Built-in-Test (BIT) capability. It delivers reliable control of external devices through 32 Form C (SPDT) relays, supporting switching voltages to 220 VDC and 250 VAC with maximum switching current of 2 A. The board accommodates 8-, 16-, or 32-bit data transfers across four 8-bit-wide ports, each addressable within the short I/O memory space. Jumper-selectable address modifiers configure short supervisory or non-privileged I/O access modes. A Control and Status Register manages the front panel Fail LED, BIT functions, and relay enable/disable operations.

– Technical Specifications

• Channels: 32 relay output channels
• Relay Type: Form C (SPDT) per channel
• Maximum Switching Power: 60 W, 125 VA
• Maximum Switching Voltage: 220 VDC, 250 VAC
• Maximum Switching Current: 2 A (DC or AC)
• Maximum Carry Current: 3 A (DC or AC)
• Contact Life (Mechanical): 10⁸ at 180 CPM
• Contact Life (Electrical): 5 × 10⁵ at 2 A 30 VDC; 2 × 10⁶ at 1 A 30 VDC
• UL/CSA Rating: 0.6 A at 110 VDC; 0.6 A at 125 VAC; 2.0 A at 30 VDC
• Data Transfer Modes: 8-, 16-, or 32-bit
• Output Organization: Four ports, 8 bits wide
• Form Factor: Double-height VME board

– Key Features

• Built-in-Test monitors all active board components and relay coil states
• Off-line test mode with disabled relay drivers and data path verification
• On-line operation with active relay drivers and inverted read-back from output registers
• Fail LED front panel indicator (illuminated at power-up, software-controlled extinguish)
• Address selection jumpers for short I/O memory map configuration
• Factory-configured for short supervisory I/O access

– Typical Applications

External device control, industrial automation switching, test and measurement systems, distributed I/O architectures.

– Compatibility & Integration

Designed for VMEbus-compliant systems with double-height mechanical compatibility and standard VME electrical specifications.
