The Adlink cPCIS-6130R/PW is a 2-slot CompactPCI rackmount chassis engineered for industrial telecom, data center, and enterprise deployments. This 1U, 19-inch rackmount unit accommodates 6U CompactPCI cards with a hot-swap backplane compliant to PICMG 2.0 R3.0 and PICMG 2.1 R2.0 standards. The chassis delivers a 64-bit/66 MHz cPCI bus across two board slots—one system slot and one peripheral slot—each supporting rear I/O via 80 mm Rear Transition Modules.
– Technical Specifications
Mechanical & Environmental
• Dimensions: 482.6 × 43.9 × 302.7 mm (W × H × D with handle)
• Weight: 4.5 kg (9.9 lbs) including power supply and backplane
• Operating Temperature: 0°C to 50°C
• Storage Temperature: −20°C to 80°C
• Humidity: 5% to 95% non-condensing
• Non-operational Shock: 15 G peak-to-peak, 11 ms duration
• Non-operational Vibration: 1.88 Grms, 5–500 Hz per axis
• Operational Vibration: 0.5 Grms, 5–500 Hz per axis
• NEBS Level 3 design compliance
Power Supply
• Type: 200 W ATX AC
• Input: Universal 100–240 ±10% V AC, 50–60 ±5% Hz
• PFC: 0.95 typical; meets IEC1000-3-2 harmonic correction
• DC Outputs: +5 V @ 16 A, +3.3 V @ 14 A, +12 V @ 9 A, −12 V @ 0.7 A
• Maximum Output: 110 W (+5 V, +3.3 V); 186 W (+5 V, +3.3 V, +12 V)
• Efficiency: 65% at 115 V full load
• Protections: Overload (110%–160%), overvoltage on +5 V and +3.3 V, short-circuit per output
Cooling
• Seven 12 V DC brushless VAPO-bearing fans
• Rear intake/exhaust: Two intake + one exhaust @ 10.8 CFM each, 8200 ±1000 RPM, 1.6 W each
• Front board exhaust: Three fans @ 8 CFM each, 7000 ±1000 RPM, 1.2 W each
• Removable air filter for maintenance
– Key Features
• Hot-swap backplane supporting both system and peripheral slots
• Guarded power switch and reset button to prevent accidental actuation
• Dual-channel intake and exhaust airflow for effective thermal management
• Overload and overvoltage protection across all voltage rails
– Typical Applications
Telecom data centers, enterprise server deployments, and industrial control systems requiring ruggedized, standards-compliant CompactPCI infrastructure.
– Compatibility & Integration
Accepts 6U CompactPCI boards with P3, P4, and P5 connector configurations. Rear I/O expansion via 80 mm RTM form factor.
