The Adtech 400120C is a 16-slot mainframe chassis designed as the core platform for broadband test systems within the AX/4000 series. This AC-powered unit provides the structural and electrical foundation for a modular test configuration, accommodating up to 16 slots for Adtech modules and interface boards. Engineers configure the chassis by populating slots with application-specific test modules, enabling customized measurement setups for broadband applications.
– Technical Specifications
• Model: Adtech 400120C
• Series: AX/4000
• Type: Broadband Test System Mainframe Chassis
• Slot Configuration: 16 slots
• Power Input: AC powered
• Operating Temperature Range: 0℃ to 60℃
– Key Features
• 16-slot chassis architecture for flexible module placement
• AC power supply design for standard laboratory environments
• Accepts full range of Adtech AX/4000 series plug-in modules and interface cards
• Modular construction allows configuration changes without mainframe replacement
– Typical Applications
The 400120C serves as the test bed for broadband communications test systems, telecommunications equipment validation, and general-purpose modular instrumentation where custom test configurations are required.
– Compatibility & Integration
The chassis is fully compatible with all Adtech AX/4000 series modules and interface boards. Integration requires proper AC power supply connection with grounding resistance less than 4 ohms. Operating environments should avoid excessive heat, humidity, dust, and corrosive gases. In high-vibration environments, rubber isolation cushions are recommended. For sustained operation at elevated ambient temperatures, active heat dissipation fan installation is advised to maintain component service life. Long-term storage requires power supply disconnection.
