The Advanced Energy/Artesyn 7001540-J000 is a 573W internal server AC power supply engineered for high-density computing environments. This µMP Series GEN II unit delivers stable, efficient power conversion across wide input ranges with active inrush control and multi-output rail architecture. The supply combines 91% typical efficiency with 0.99 power factor and 80 PLUS compliance for mission-critical server and storage applications.
– Technical Specifications
Input Characteristics
• Input voltage range: 100–240 VAC
• Input frequency: 50–60 Hz
• Maximum input current: 7.20A
• AC inrush control: Active, limited to 40A maximum at turn-on
Output Rails
• +12V: 40A maximum (575W at full load)
• +5.1V: 30A maximum
• +3.36V standby: 0.45A maximum
Performance
• Rated power: 573W
• Efficiency: Up to 91% typical (180–264 VAC at full load); 90.74% typical at 50% load with 230V input
• Power factor: 0.99 typical
• 80 PLUS certified
Physical Interface
• Form factor: Internal
• Ejector handle included
• Status LEDs for operational indication
– Key Features
• Multi-voltage output configuration optimized for server motherboards and peripheral circuits
• Active AC inrush limiting protects upstream distribution and reduces nuisance breaker trips
• High power factor design minimizes reactive power draw in facility infrastructure
• Standby rail supports low-power system management during sleep states
• Integrated status monitoring via LED indicators
– Typical Applications
Internally mounted server PSUs for rack-mount systems, storage arrays, and compute nodes requiring dual-voltage (12V/5V) architecture with standby power capability.
– Compatibility & Integration
Part of the Artesyn µMP Series GEN II configurable platform. Listed as compatible with HP/Emerson StorageWorks MSA2000 storage systems.
