The Advanced Energy / Artesyn SSL40-7612 is a 40W single-output external AC/DC power supply engineered for low-power, portable, and desktop applications in data networking, computing, and industrial environments. Universal input acceptance across 90–264 VAC with free air convection cooling eliminates the need for active thermal management, while a molded UL94V-0 plastic enclosure delivers compact dimensions suitable for space-constrained installations. The unit integrates overvoltage and short-circuit protection, 3 kVAC isolation voltage, and operates across 0 °C to +40 °C with a maximum rating of +70 °C.
– Technical Specifications
• Output Power: 40W
• Input Voltage: 90–264 VAC universal input
• Output Voltage: 12V typical
• Output Current: 3A typical (at 12V)
• Efficiency: 70–80% typical
• Isolation Voltage: 3 kVAC
• Switching Frequency: 72 kHz typical
• Hold-up Time: 10 ms at 115 VAC, full load
• Operating Temperature Range: 0 °C to +40 °C
• Maximum Operating Temperature: +70 °C
• Enclosure Dimensions: 4.65 × 2.40 × 1.08 inches
• Weight: 200 g (7 oz)
– Key Features
• Free air convection cooling eliminates fan noise and maintenance
• Universal AC input (90–264 VAC) accommodates global mains variations
• Overvoltage and short-circuit protection
• UL, CSA, VDE, and CE safety approvals
• FCC and EN55022 emissions compliance (Level B)
• 3 ft DC output cord with 2.5 mm phone jack connector
• Compact molded plastic enclosure (UL94V-0 rated)
– Typical Applications
• Lighting and display systems
• Data networking equipment
• Desktop and portable computing devices
• General industrial electronics
– Compatibility & Integration
The SSL40-7612 provides universal AC input connectivity and delivers 12V DC output via a 2.5 mm phone jack connector with 3 ft cord. Integration into systems requiring low-power DC conversion at 40W capacity makes it suitable for a broad range of electronic devices across commercial and industrial sectors.
