The Advantest Q82032A is an optical sensor head designed for integration with Advantest optical power meters and spectrum analyzers. This unit provides accurate optical parameter sensing and measurement capabilities in laboratory and field optical measurement setups. The sensor head connects to compatible Advantest instruments and supports data acquisition workflows via GPIB interface to personal computers.
– Technical Specifications
• Product Type: Optical Sensor Head
• Measurement Data Storage: Up to 400 data points per channel (Channels A and B)
• Physical Dimensions: 10 × 8 × 6 inches
• Weight: 5 lbs
• Operating Voltage: 220/240 VAC (fuse adjustment available for 100/120 VAC operation)
– Key Features
• Dual-channel measurement data logging capability
• GPIB interface for direct computer integration and data retrieval
• Compact form factor suitable for bench and rack-mounted installations
• Designed for the Advantest optical measurement ecosystem
– Typical Applications
• Optical power measurement and monitoring
• Spectrum analysis in fiber-optic systems
• Multi-point optical parameter data acquisition
• Laboratory optical characterization and testing
• System performance validation and troubleshooting
– Compatibility & Integration
The Q82032A integrates directly with Advantest TQ8210 Optical Power Meter and operates within the broader Advantest optical instrumentation platform. Data acquired by the sensor head can be logged locally (up to 400 points per channel) and transferred to external computers via GPIB for further analysis and archiving. The unit is part of a modular family of Advantest optical sensor heads including the Q82227, Q82214, Q82202, Q82208, Q82223, and Q82215.
