Advantest Q82232 900nm-1650nm Optical Sensor

The Advantest Q82232 is a plug-in optical sensor module engineered for precision optical power measurement across the 900nm to 1650nm wavelength band. Built around a cooled InGaAs photodiode, it delivers measurement speeds up to 100 times/sec with noise performance of -94 dBm and dynamic range spanning -80 to +27 dBm. The sensor minimizes polarization dependence to 0.003 dBp-p or less, making it ideal for fiber-coupled optical testing, component characterization, and laser diode validation in both research and production environments.

– Technical Specifications

• Wavelength Range: 900nm – 1650nm
• Power Measurement Range: -80 to +27 dBm
• High Power Linearity: Up to +10 dBm
• Measurement Speed: Up to 100 times/sec
• Ranging Speed: 20 msec (minimum) to 500 msec (maximum)
• Noise Level: -94 dBm
• Polarization Dependence: 0.003 dBp-p or less
• Accuracy at Calibration Point: ±2.5%
• Accuracy (Broadband with Sensitivity Compensation): ±4.5%
• Linearity: ±0.5%
• Return Loss (Slant Polished Fiber): 50 dB or more
• Return Loss (PC Polished with High-Return-Loss Adaptor): 45 dB or more (typical)
• Sensor Element: Cooled InGaAs photodiode
• Optical Input: 10 µm core diameter, NA 0.19 or less
• Connectors: FC, SC, ST, MU, LC, and plug-in types
• Internal Memory: 400 data points per channel (A and B)
• Data Interface: GPIB at up to 100 times/sec

– Key Features

• Automatic sensitivity compensation based on entered wavelength
• Dual measurement modes: CW (continuous) or chopped light (270Hz, 2kHz, 4kHz)
• Independent dual-channel measurement capability
• Low-noise design supports demanding production testing and metrology

– Typical Applications

• Optical fiber characterization and testing
• Laser diode performance validation
• Optical component power measurement
• Production line quality control

– Compatibility & Integration

The Q82232 operates as a plug-in unit with compatible Advantest main units such as the Q8221. Pairs with the Q8163 Polarization Scrambler for high-speed, high-precision PDL measurements.
