The Advantest R3966B is a 3-port test adapter engineered for S-parameter measurement and multi-port device characterization. It enables accurate testing of three-port networks without requiring device reconnection, optimizing measurement efficiency across comprehensive performance assessments.
– Technical Specifications
The R3966B interfaces with Advantest’s R3765CH and R3767CH network analyzers to deliver S-parameter measurements across all three ports simultaneously.
– Key Features
• Three-port measurement capability for multi-port device testing
• S-parameter characterization without device connection changes
• Direct integration with compatible Advantest network analyzer platforms
• Streamlined operator interface for efficient measurement workflows
– Operating Requirements
The adapter requires adequate ventilation with minimum 10 cm clearance around all air vents to support internal cooling fan operation. Horizontal mounting orientation is mandatory. The instrument must operate in environments free from sudden temperature fluctuations, mechanical shock, vibration, moisture, dust, and electromagnetic interference sources. Power supply voltage must match unit specifications; connection to a properly grounded outlet with appropriately rated fuses is required. Live operation with the case open is prohibited. Do not subject the unit to mechanical stress, impact, or liquid exposure during powered operation.
– Compatibility & Integration
• Advantest R3765CH network analyzer
• Advantest R3767CH network analyzer
– Product Status
The Advantest R3966B is a discontinued product.
