Affinity FAA-050K Lytron Air Cooled Chiller

The Affinity FAA-050K is an air-cooled chiller engineered for precise thermal management in demanding industrial and laboratory environments. This unit delivers consistent cooling performance across laser cooling, semiconductor manufacturing, and other temperature-critical processes requiring stable thermal control. The air-cooled condenser design eliminates external water infrastructure while maintaining tight temperature regulation through digital control and hot gas bypass systems.

– Technical Specifications

• Process Temperature Range: −40°F to 176°F (−40°C to 80°C); 5°C to 25°C with internal insulation package; 5°C to 35°C (41°F to 95°F) standard operation
• Ambient Temperature Range: 41°F to 95°F (5°C to 35°C); do not operate below 7°C (45°F) or above 30°C (85°C); cooling capacity derated above 30°C
• Temperature Stability: Achieves ±0.1°C with Kodiak series controllers; hot gas bypass and digital control systems ensure precision
• Refrigerant: R-507
• Storage Temperature: Maximum 52°C (125°F)
• Electrical Configuration: 208–230 V ±10% at 60 Hz or 200–220 V ±10% at 50 Hz; 3-phase; 10 ft power cord
• Maximum Fuse Disconnect: 45 A

– Key Features

• Air-cooled condenser—no external water loop required; requires regular cleaning to prevent dirt and dust accumulation
• Compatible with multiple coolants: water, deionized water, oil, or Ethylene Glycol/Water mixtures depending on heat exchanger material
• Optional deionization cartridge maintains fluid resistivity and removes ions
• PAO-compatible pump, fittings, hose, and filter configurations available
• Hot gas bypass system enables precise setpoint control
• Digital controller with RS-485 and RS-232 communications options
• WinChill Control Software integration

– Typical Applications

• Laser systems requiring stable coolant temperature
• Semiconductor manufacturing processes
• Precision laboratory equipment thermal management

– Compatibility & Integration

The FAA-050K accepts water, deionized water, oil, and Ethylene Glycol/Water mixtures—consult factory for PAO or non-standard fluid compatibility. Do not use automotive antifreeze or silicate-containing formulations, as these cause pump seal failure. RS-485 and RS-232 interfaces enable remote monitoring and control through WinChill software.
