Agilent 8720A 130MHz-20GHz Microwave Network Analyzer w 001 and 10 W CALIBRATION

The Agilent 8720A is a microwave network analyzer operating from 130 MHz to 20 GHz, delivering S-parameter and vector network measurements with dynamic range exceeding 85 dB (up to 103 dB with variable-bandwidth IF filters). The instrument integrates a swept synthesized source, switching S-parameter test set, and dual independent display channels. Option 001 provides 1 Hz frequency resolution beyond the standard 100 kHz. With built-in vector accuracy enhancement, error correction, and time-domain capabilities, the 8720A characterizes impedance, transmission, reflection, magnitude, phase, group delay, and absolute power across RF and microwave devices. Its switching test set measures all four S-parameters from a single connection, while flexible data handling via external disk drive and HP-IB programmability supports R&D, manufacturing, incoming inspection, and quality assurance workflows.

– Technical Specifications

• Frequency Range: 130 MHz to 20 GHz
• Frequency Resolution: Standard 100 kHz; Option 001 provides 1 Hz resolution
• Dynamic Range: Greater than 85 dB; up to 103 dB with variable-bandwidth IF filters
• Source Output Power: +5 dBm (typical, standard)
• Power Flatness: ±1.5 dB
• Frequency Accuracy: 10 ppm (typical)
• Synthesized Source: Fully integrated, swept, stable within 10 ppm

– Key Features

• Integrated switching S-parameter test set for all four S-parameters with single connection
• Vector receiver with built-in error correction and vector accuracy enhancement
• Dual independent display channels with multiple formats: log magnitude, linear magnitude, SWR, phase, group delay, polar, real, or Smith Chart
• Time-domain capabilities available via Option 010
• Direct save/recall to external disk drive
• Compact, fully integrated design
• HP-IB bus interface for external computer programmability

– Measurement Capabilities

• Forward and reverse S-parameter measurements
• Vector network characterization
• Impedance, transmission, and reflection properties
• Magnitude, phase, group delay, and absolute power

– Compatibility & Integration

• Compatible with 3.5 mm calibration kits (10W calibration kit supplied)
• Precision calibration standards and flexible cables consistent with HP 8510 design
• External computer control via HP-IB interface
