Agilent/Keysight 04287-60111

The Agilent/Keysight 04287-60111 is identified as a Test Head for the Keysight 4287A RF LCR Meter. The Keysight 4287A RF LCR Meter is a specialized instrument designed for accurate, reliable, and fast measurements in the frequency range of 1 MHz to 3 GHz, making it suitable for production line testing of electronic components such as SMD inductors and EMI filters. This meter utilizes a direct-current voltage-measurement technique for accurate measurements across a wide impedance range.

**Relevant Technical Details**

**Keysight 4287A RF LCR Meter (for which the 04287-60111 is a component):**

* **Test Frequency Range:** 1 MHz to 3 GHz (with 100 kHz resolution)
* **Impedance Parameters Measured:** |Z|, θz (rad), θz (deg), |Y|, θy (rad), θy (deg), X, G, B, Ls, Lp, Cs, Cp, Rs, Rp, Q, D
* **Display Resolutions:** 5 digits
* **Test Signal Level:**
* Voltage (open condition): 4.47 mVrms to 502 mVmVrms (447 mVrms when > 1 GHz)
* Current (short condition): 0.0894 mArms to 10 mArms (8.94 mArms when > 1 GHz)
* **Basic Accuracy:** ±1.0%
* **Measurement Range:** 200 mΩ to 3 kΩ (@1 MHz, accuracy ≤10%)
* **Measurement Time:** 9 msec per point (maximum speed)
* **Measurement Terminal:** 3.5 mm (female)
* **Calibration and Compensation:** Open/short/load/low-loss capacitor calibration, fixture electrical length compensation, open/short compensation
* **Rdc Measurement Function:** For contact check (selectable on/off)
* **Data Storage Devices (within the 4287A meter):** Approximately 18 GB internal hard disk and 1.44 MB floppy disk (with Option 010 – Hard-Disk Drive Mass Storage)
* **Interfaces (on the 4287A meter):** GPIB, LAN (10base-T/100base-TX auto-switched), and Opto-isolated handler interface
* **Power Requirements (for the 4287A meter):** 90 V to 132 V, or 198 V to 264 V (auto-switched), 47 Hz to 63 Hz operation
* **Physical Dimensions (of the 4287A meter):** 221.62 mm (8.725 in) H x 425.6 mm (16.75 in) W x 466.2 mm (18.35 in) D
* **Weight (of the 4287A meter):** 36 lb

**04287-60111 Component:**

* **Description:** TEST HEAD for 4287A
* **Associated Equipment:** Keysight 4287A RF LCR Meter
