Agilent/Keysight 11792A

The Agilent/Keysight 11792A is an RF power sensor module engineered for precision power measurements spanning 50 MHz to 26.5 GHz. It integrates with the Agilent 8902A measuring receiver and, when paired with the 11793A microwave converter, extends measurement capability to the full upper frequency limit. The module delivers accurate characterization of AM, FM, and phase modulation across its operating range with exceptional linearity and return loss performance.

– Technical Specifications

Frequency Range: 50 MHz to 26.5 GHz

Power Measurement Range:
• Standard: +30 dBm (1 W) to -20 dBm (10 μW); down to -100 dBm with specific configurations
• IF Synchronous Detector: +10 dBm to -117 dBm (2.5 MHz ≤ fc ≤ 1300 MHz); +5 dBm to -105 dBm (1300 MHz ≤ fc ≤ 12.4 GHz); +5 dBm to -100 dBm (12.4 GHz ≤ fc ≤ 18.0 GHz); +5 dBm to -95 dBm (18.0 GHz ≤ fc ≤ 26.5 GHz)
• IF Average Detector: +10 dBm to -90 dBm (2.5 MHz ≤ fc ≤ 1300 MHz); +5 dBm to -80 dBm (1300 MHz ≤ fc ≤ 12.4 GHz); +5 dBm to -75 dBm (12.4 GHz ≤ fc ≤ 18.0 GHz)

Connector: 3.5 mm (m); Type-N option (Option 001, limited to 18 GHz)

Impedance: 50 ohms

Return Loss (Input SWR):
• <1.10 (f ≤ 2.0 GHz)
• <1.28 (2.0 GHz < f ≤ 18.0 GHz)
• <1.40 (18.0 GHz < f ≤ 26.5 GHz)
• 1.05 nominal

Linearity: ±0.02 dB within range; ±0.02 dB per range change from reference ± 1 digit

Calibration: Individually determined and traceable to U.S. National Bureau of Standards. System accuracy improvement available with Option 050 on 8902A receiver.

– Key Features

• Measures AM, FM, and phase modulation including residuals and incidentals
• Minimal signal loss and reflection across full frequency span
• Internal on/off switching controlled by host receiver
• Compact form factor: 51 mm (H) × 62 mm (W); 0.8 kg net weight
• Supplied with 925 mm RF cable and 944 mm sensor cable

– Compatibility & Integration

Designed for the Agilent 8901B modulation analyzer and 8902A measuring receiver. Extended measurement to 26.5 GHz achieved through pairing with the 11793A microwave converter.
