Agilent/Keysight 16048G

The Keysight 16048G is a 1-meter port extension cable that bridges Keysight impedance analyzers to devices under test via a 4-terminal pair configuration. It extends measurement ports from the instrument’s terminals to the DUT and accepts user-fabricated test fixtures through its BNC male connector board. The cable supports DC bias voltage application, enabling comprehensive impedance characterization across a wide frequency range.

– Technical Specifications

Electrical Performance
• Frequency range: DC to 120 MHz
• Maximum voltage: ±42 V peak (AC+DC combined)
• 4-terminal pair configuration
• BNC female cable tip interface

Physical
• Cable length: 1 meter
• Weight: Approximately 460 g

Environmental
• Operating temperature: -20°C to +150°C (excluding up to 20 cm from the four-terminal pair connection block)
• Operating humidity: 15% to 95% RH (wet bulb temperature < 40°C)
• Non-operating temperature: -40°C to +70°C
• Non-operating humidity: ≤90% RH (wet bulb temperature < 65°C)

– Key Features

• BNC male connector board designed for user-fabricated test fixture integration
• DC bias capability for impedance measurements on active components
• 4-terminal pair kelvin configuration eliminates lead resistance errors
• Extended cable length reduces measurement uncertainty from probe placement

– Typical Applications

• Impedance characterization of discrete and integrated components
• High-frequency capacitor and inductor measurements
• Component testing with applied DC bias
• Laboratory-built fixture integration for custom test scenarios

– Compatibility & Integration

The 16048G connects directly to Keysight E4990A and Agilent/HP 4294A impedance analyzers. For the E4990A, select "4TP 1M" in the adapter setup menu before measurement. Adapter setup using a 100 Ω reference resistor for phase compensation is recommended prior to testing.
