Agilent/Keysight 44715A

The Agilent/Keysight 44715A is a five-channel counter/totalizer component module for high-performance measurement and event counting applications. Each channel operates at 200 kHz and can be hardware-configured to one of four distinct operating modes, supporting count, frequency, and period measurements. The modular architecture integrates directly into larger data acquisition systems, enabling flexible multi-channel monitoring with event-driven interrupt capability. This unit combines a Counter Component Module and Terminal Module for seamless deployment in controlled measurement environments.

– Technical Specifications

• Module Type: 5-Channel Counter/Totalizer Component Module
• Counter Frequency: 200 kHz
• Operating Modes: Four hardware-selectable modes per channel
• Programmable Functions: Count, frequency, and period measurements
• Event Processing: Interrupt support for event-driven applications

– Key Features

• Five independent counter channels with dual-module design
• Hardware mode configuration eliminates software complexity
• Direct interrupt integration for time-critical measurement tasks
• Terminal and counter modules ship as integrated unit

– Typical Applications

Suitable for cumulative event analysis, frequency measurement over extended periods, and period characterization in industrial test and laboratory environments where modular scalability is required.

– Compatibility & Integration

Designed for integration into the Agilent 3852A data acquisition and control system, which provides eight slots for plug-in function modules. Systems can be expanded using the 3853A expansion unit, allowing multi-module configurations for distributed measurement across numerous channels.
