The Agilent/Keysight 6294A is a compact DC power supply delivering 0 to 60 VDC at 0 to 1 A output, designed for electronic testing, circuit development, and low-power device characterization. Dual-mode operation supports both constant voltage and constant current delivery, with integrated metering for real-time voltage and current monitoring. The instrument features a 10-turn voltage control potentiometer and a dual-range front-panel meter covering 0–7 V, 0–70 V, 0–0.12 A, and 0–1.2 A ranges. Built-in overvoltage and overcurrent protection safeguard connected loads. Remote programming capability enables integration into automated test systems. Though discontinued, the 6294A remains operational for legacy applications and specialized testing requirements.
– Technical Specifications
• Output Voltage: 0 to 60 VDC
• Output Current: 0 to 1 A
• Operation Modes: Constant Voltage / Constant Current
• Front Panel Meter: Dual-range, 0–7 V / 0–70 V / 0–0.12 A / 0–1.2 A
• Voltage Control: 10-turn potentiometer
• Protection: Overvoltage and overcurrent
• Remote Programming: Supported
– Key Features
• Precision voltage and current metering for circuit-level diagnostics
• Compact form factor suited to lab benches and test stations
• Dual-range front-panel meter eliminates frequent scale switching
• Safety Class I construction with three-conductor grounding requirement
• Independent constant-voltage and constant-current regulation modes
– Typical Applications
• Small-signal circuit testing and characterization
• Sensor power and validation
• Low-power device development and troubleshooting
• Educational laboratory use
– Compatibility & Integration
Remote programming support allows integration into automated measurement systems and test sequences. The 6294A is a legacy product; Keysight’s E3645A series offers current-generation equivalents for new system designs.
