Agilent/Keysight 6671A DC Power Supply

The Agilent/Keysight 6671A is a 2000 W DC power supply engineered for high-current applications requiring precision voltage and current regulation. Single output delivers 0 to 8 Vdc at 0 to 220 A, with programmable constant voltage (CV) and constant current (CC) operation modes. GPIB interface enables remote control and integration into automated test systems. The unit combines tight load regulation, low ripple performance, and comprehensive protection—including programmable overvoltage, overcurrent, and over-temperature safeguards—making it suitable for demanding industrial and laboratory environments.

– Technical Specifications

Output voltage ranges from 0 to 8 Vdc with output current from 0 to 220 A, delivering 1760 W actual output power. Programming accuracy (at 25°C ±5°C) specifies voltage to 0.04% + 8 mV and current to 0.1% + 125 mA. Load regulation holds voltage to 0.002% + 300 µV and current to 0.005% + 10 mA. Ripple and noise performance (20 Hz to 20 MHz) measures 650 µV rms and 7 mV peak-to-peak for voltage; current ripple reaches 200 mA rms. Readback accuracy (at 25°C ±5°C) provides voltage measurement to 0.05% + 12 mV and current to 0.1% + 150 mA. AC input operates from 191 to 250 Vac, 47–63 Hz.

– Key Features

• Programmable over-voltage, over-current, and over-temperature protection
• GPIB interface with SCPI programming and talker/listener functionality
• Auto-parallel capability supporting up to five units; serial link allows up to 16 supplies on single GPIB bus
• Series and parallel output configurations supported
• Analog control of voltage and current with user-definable power-on state
• Fan-speed control for acoustic noise reduction
• Self-test via GPIB command at power-on
• Discrete Fault Indicator/Remote Inhibit (DFI/RI) output
• VXI plug & play drivers available for system integration

– Typical Applications

High-current DC power delivery for materials testing, semiconductor device characterization, electrochemistry, power converter validation, and automated production test systems.

– Compatibility & Integration

Compatible with Agilent measurement and control software. VXI plug & play drivers support integration into VXI systems. Dimensions: 133 mm H × 426 mm W × 640 mm D. Weight: 62 lb.
