The Keysight 70611A is an Attenuator-Switch Driver module engineered for integration within the Keysight 70000 series modular measurement system. It provides signal attenuation and switching control across distributed RF and microwave signal paths, capable of driving up to 248 external devices. This single-slot module communicates with the mainframe via the Modular Signal Switching (MSS) bus for high-speed digital control or GPIB for computer-based instrument control, enabling precise signal path management in spectrum analyzers and complex test configurations.
– Technical Specifications
• Module type: Attenuator-Switch Driver
• Device drive capacity: 248 devices maximum
• Form factor: 1-slot width for 70000 series mainframe
• System integration: MSS bus and GPIB interfaces
– Key Features
• High-speed digital communication via Modular Signal Switching (MSS) bus for real-time signal control
• GPIB compatibility for remote instrument command and monitoring
• Designed for operation within 70000 series power and thermal management architecture
• Optimized EMC performance and mechanical design for industrial measurement environments
– Typical Applications
• Signal attenuation and routing in spectrum analysis systems
• Switched RF and microwave measurement configurations
• Multi-device control in distributed test setups requiring centralized switching
• Sensitive measurements in electromagnetically challenging environments
– Compatibility & Integration
The 70611A integrates with Keysight 70000 series modular spectrum analyzer mainframes, operating alongside Local Oscillator modules (70900A, 70900B), display modules (70004A), and signal analyzer modules. The mainframe supplies power, thermal management, and digital communication infrastructure. Both MSS bus and GPIB communication paths enable flexible system configuration and control architecture.
