The Agilent/Keysight 70907A is a downconverter module that extends the frequency measurement capabilities of 70000 series spectrum analyzers to lower frequencies. Operating as a mixer, it downconverts higher frequency input signals to intermediate frequency (IF) ranges suitable for processing by the host analyzer. This architecture enables users to analyze signals below the inherent low-frequency limit of the spectrum analyzer operating independently, significantly broadening measurement coverage across a wider signal spectrum.
– Technical Specifications
Frequency Coverage
• Downconversion to intermediate frequency compatible with 70000 series spectrum analyzer architecture
• Extends measurement capability to frequencies below the standalone analyzer’s lower limit
• Input and output frequency ranges determined by host spectrum analyzer configuration and module design
Signal Processing
• Noise figure enhancement through integrated preamplification stages
• Gain-based architecture for low-level signal detection and signal-to-noise ratio improvement
– Key Features
• Plug-in module for 70000 series spectrum analyzer mainframes
• Downconversion topology for extended frequency coverage
• Preamplification integration for enhanced system performance on weak signals
– Typical Applications
• Low-frequency signal measurement and analysis
• Broadband spectrum characterization below analyzer native low-frequency limit
• Extended dynamic range analysis on weak or low-level signals
– Compatibility & Integration
The 70907A is designed exclusively for integration into Agilent/Keysight 70000 series spectrum analyzer platforms. As a modular component within the 70000 series architecture, it provides specialized downconversion capabilities as part of the broader ecosystem of available measurement modules.
