The Keysight 81010BL is an optical lens accessory engineered to reduce beam size on the detector in Keysight optical test systems. Installed between an optical head and fiber connector adapter, it enhances measurement accuracy across multiple wavelengths and fiber types. This compact lens module supports single-mode fiber at 1300 nm and 1550 nm, as well as multimode fiber at 850 nm, making it suitable for telecommunications, data communications, and precision optical characterization work.
– Technical Specifications
• Product Type: Optical Lens Accessory
• Manufacturer: Keysight / Agilent
• Model: 81010BL
• Supported Wavelengths: 850 nm (MMF), 1300 nm (SMF), 1550 nm (SMF)
• Fiber Types: Single-mode fiber (SMF), Multimode fiber (MMF)
• Function: Beam size reduction on detector; interfaces between optical head and fiber connector adapter
• Status: Obsolete
– Key Features
• Compact lens module design for direct integration into optical test setups
• Wavelength coverage spanning 850 nm multimode and 1300/1550 nm single-mode bands
• Reduces detector beam size to improve measurement precision
• Compatible with multiple connector adapter types: FC/PC/SPC/APC, SC/PC/APC, LC, ST, E-2000, and others
– Typical Applications
• Optical power meter and optical head performance enhancement
• Telecommunications and data communications fiber optic testing
• Semiconductor fabrication and testing environments requiring precise optical signal analysis
• Research and development in optical communications and signal characterization
– Compatibility & Integration
The 81010BL integrates with Keysight 815xxx and 816xxx series optical heads. Connection occurs through compatible fiber connector adapters in the 81000xx and 81001xx series, which support both 5 mm and 3 mm optical head configurations. Connector adapter selection determines the specific interface type (FC, SC, LC, ST, E-2000) for the test setup.
