Agilent/Keysight 8167B,Lightwave Test System

The Agilent/Keysight 8167B is a tunable optical source engineered for precision characterization of optical components and systems across research, development, and manufacturing environments. Delivering stable, accurate optical signals from 1200 nm to 1650 nm with 1 pm wavelength resolution and ±20 pm accuracy, the 8167B provides continuous-wave output up to +20 dBm with exceptional power stability of ±0.01 dB over 1 hour. The benchtop instrument features a 7-inch color LCD display, front-panel controls, and full programmability via GPIB, LAN, USB, and RS-232 interfaces. Remote operation and SCPI command support enable integration into automated test systems. Operating from 0 °C to +45 °C in environments up to 2000 m altitude, the 8167B maintains performance under demanding laboratory and production conditions. Compact at 430 × 220 × 485 mm and weighing 10.0 kg, it integrates with Keysight optical instruments including the 8163B, 8164B, and 8166B mainframe systems.

– Technical Specifications

• Wavelength range: 1200 nm to 1650 nm
• Output power: Up to +20 dBm (configuration and wavelength dependent)
• Wavelength resolution: 1 pm
• Wavelength accuracy: ±20 pm
• Power stability: ±0.01 dB over 1 hour (typical)
• Output mode: Continuous wave (CW)
• Input voltage: AC 100–240 V ± 10%, 50/60 Hz
• Power consumption: 450 VA maximum
• Operating temperature: 0 °C to +45 °C
• Storage temperature: −40 °C to +70 °C
• Humidity: < 95% RH from 0 °C to 55 °C
• Maximum operation altitude: 2000 m

– Key Features

• High-resolution wavelength tuning across extended range
• Precision optical signal generation for component and system testing
• Multiple interface options: GPIB, LAN, USB, RS-232
• 7-inch high-resolution color LCD display
• Programmable via SCPI commands for test automation
• Compact benchtop form factor (10.0 kg)
• Wide operating temperature and altitude specifications

– Typical Applications

• Optical component characterization and validation
• Lightwave system development and troubleshooting
• Manufacturing test and quality assurance
• Research and laboratory optical measurements

– Compatibility & Integration

Designed for integration with Keysight optical instruments including the 8163B, 8164B, and 8166B mainframe systems within the Agilent/Keysight Lightwave series.
