Agilent / Keysight 85047A S-Parameter Test Set, 300 kHz to 6 GHz

The Agilent/Keysight 85047A S-Parameter Test Set enables accurate characterization of RF and microwave devices from 300 kHz to 6 GHz. It measures transmission and reflection characteristics—including all S-parameters—of one-port or two-port devices in either direction with a single connection. The test set integrates with Agilent/HP 8753B/C, 8753D/E/ES network analyzers and selected 8702 Lightwave Component Analyzer configurations, supporting full two-port error correction and calibration workflows.

Solid-state test port switches deliver faster measurement speeds, superior repeatability (±0.03 dB), and extended operational life compared to mechanical alternatives. The design enables simultaneous monitoring of any two S-parameters on the display—such as forward gain and output match—while maintaining continuous S-parameter updates during full two-port error correction. Two-port sweeps with 101 points or more benefit from a 160 millisecond speed improvement per trace update.

– Technical Specifications

• Frequency Range: 300 kHz to 6 GHz
• Operating Modes: 300 kHz to 3 GHz (frequency doubler switched out); 3 MHz to 6 GHz (frequency doubler switched in)
• Impedance: 50 Ohms
• Directivity: ≥35 dB (300 kHz to 1.3 GHz); ≥30 dB (1.3 GHz to 3 GHz); ≥25 dB (3 GHz to 6 GHz)
• Effective Source Match: ≥20 dB (300 kHz to 1.3 GHz); ≥16 dB (1.3 GHz to 3 GHz); ≥14 dB (3 GHz to 6 GHz)
• Switch Repeatability: ±0.03 dB
• Insertion Loss: <5 dB (RF input to test ports)
• Test Port Power: 15 dBm
• Programmable Step Attenuator: Included

– Key Features

• Solid-state switching technology for improved accuracy and reliability
• Simultaneous dual S-parameter display capability
• 160 millisecond speed improvement for 101-point and larger sweeps with full two-port correction
• Single-connection measurement of both forward and reverse device characteristics

– Typical Applications

• Two-port RF component characterization and validation
• Production and verification testing of microwave devices
• System-level S-parameter measurement and error correction

– Compatibility & Integration

Operates with Agilent/HP 8753B/C, 8753D/E/ES network analyzers and selected 8702 configurations. For 6 GHz operation with 8753B/C and 8702 analyzers, Option 006 (6 GHz receiver) is required. The 8753D/E/ES and selected 8702 units with built-in 6 GHz sources do not require the frequency doubler.
