Agilent/Keysight 8511A

The Agilent/Keysight 8511A is a four-channel frequency converter test set engineered for operation with the Agilent/Keysight 8510C Network Analyzer. It functions as a general-purpose magnitude and phase receiver with four RF to IF converters, enabling S-parameter measurements and advanced network analysis across a broad frequency range. The instrument accommodates multiport devices, subsystems, and antenna characterization through three measurement inputs after one input is reserved for system phase-lock. Precision 3.5 mm connectors on all inputs ensure signal integrity from 45 MHz to 26.5 GHz.

– Technical Specifications

• Frequency range: 45 MHz to 26.5 GHz
• Four-channel receiver with four separate RF to IF converters
• Input connectors: Precision 3.5 mm on all channels
• Excellent RF source tracking
• Operating temperature: 0 °C to 55 °C
• Power requirements: 110, 120, 220, or 240 ±10% VAC at 47–66 Hz
• Dimensions: 460 mm × 133 mm × 609 mm (18.1 × 5.25 × 24 inches)
• Weight: 13 kg (29 lb) net; 17 kg (38 lb) shipping

– Key Features

• Four-channel magnitude and phase receiver architecture
• Dual-mode measurement support: transmission (with external power splitters) and reflection (with bridges or directional couplers)
• Direct integration with 8510C Network Analyzer
• Optional H40 frequency extension to 40 GHz with 2.4 mm female test ports
• Rackmount capability via 913 Rackmount kit

– Typical Applications

• Research and development of RF/microwave components
• Manufacturing test environments requiring multiport device characterization
• Antenna measurement and analysis
• Subsystem S-parameter verification

– Compatibility & Integration

• Designed to operate with Agilent/Keysight 8510C Network Analyzer
• Performance verification software available for 8511A/B and antenna measurement systems
