The Agilent/Keysight 8546A is a specialized EMI receiver for electromagnetic interference compliance testing and electromagnetic compatibility measurements. Operating from 9 kHz to 6.5 GHz, it delivers simultaneous peak, quasi-peak, and average amplitude measurements across three tuning bands. CISPR 16-1 compliant, the 8546A supports international standards including CISPR, EN, FCC, VCCI, and VDE, making it essential for modern high-speed equipment qualification.
– Technical Specifications
Frequency Coverage
• 9 kHz to 6.5 GHz overall
• Band 1: 9 kHz to 50 MHz
• Band 2: 20 MHz to 2.9 GHz
• Band 3: 1 GHz to 6.5 GHz
Amplitude Measurement
• Simultaneous peak, quasi-peak, and average detection
Frequency Reference
• Aging: <±1 × 10⁻⁷/year
• Settability: <±1 × 10⁻⁸
• Temperature stability (1 GHz to 6.5 GHz): <±1 × 10⁻⁸
Input Handling
• Band 1: 2 kW peak for 10 µs (≥20 dB attenuation)
• Band 2: 100 W peak for <10 µs, <1% duty cycle (≥30 dB attenuation)
• Continuous: 137 dBµV (30 dBm) from 9 kHz to 6.5 GHz
• Peak pulsed (preamp off): 50 dBm (100 W) for 10 µs, 1% duty cycle
• DC coupled: 0 V; AC coupled: 50 V
Power Supply
• 90–132 Vrms or 198–264 Vrms, 47–440 Hz
• On: <615 VA, <265 W (full); <500 VA, <180 W (RF section only)
• Off: <5 W
Operating Conditions
• Temperature: 0 °C to +55 °C
• Probe power: +15 Vdc ±7% at 150 mA max
– Key Features
• Three independent tuning bands eliminate dead zones
• Simultaneous amplitude detection modes accelerate EMI characterization
• Built-in spectrum analyzer and time-domain scan functionality
• Automated test routines reduce compliance cycle time
• Frequency reference stability ensures long-term measurement confidence
– Interfaces & Integration
• HP-IB (GPIB) standard for remote control
• RS-232 available with Option 023
• Type-N female connectors (tracking generator, calibrator signal)
• Calibrator signal: 300 MHz, –20 dBm ±0.4 dB
• Earphone jack for audio monitoring
• Compatible with Keysight 85422E/85462A external modules
