Agilent/Keysight 85532B

The Agilent/Keysight 85532B is a CalPod (Calibration Pod) designed to enable in-situ calibration refreshes within thermal-vacuum chamber environments without removing the Device Under Test or reconnecting calibration standards. This calibration refresh module integrates with Keysight PNA and PXIe vector network analyzers to eliminate thermal effects from test cables and connectors, maintaining measurement accuracy across demanding aerospace and satellite testing applications.

– Technical Specifications

• Frequency Range: 100 MHz to 20 GHz
• Connector Type: 2.92 mm
• Operating Temperature: -30 °C to +80 °C
• Re-correction Accuracy:
– Amplitude: ±0.05 dB (typical)
– Phase: ±1.5° (typical)
– Directivity: -38 dB (typical)
• Maximum CalPods Controllable: Up to 48 units
• Simultaneous Re-correction Limit: 4 CalPods

– Key Features

• In-situ calibration capability eliminates DUT removal during thermal-vacuum testing
• Rapid calibration refresh with minimal measurement downtime
• Requires 85523B CalPod Controller for operation
• Supports fan-out expansion via 85556A cable splitter for systems exceeding 4 CalPods
• Compatible with ECal module characterization for use as an ECal module in measurement environments
• Operates across wide temperature range critical to environmental stress testing

– Typical Applications

• Thermal-vacuum chamber recalibration and re-correction
• Aerospace component and satellite subsystem characterization
• Long-duration environmental stress testing requiring periodic measurement validation
• Multi-DUT test environments where recalibration efficiency is paramount

– Compatibility & Integration

The 85532B integrates with the following Keysight instruments:

• PNA Family: PNA-X N524xA, PNA N522xA, PNA-L N5231/32/34/35/39A
• PXIe Vector Network Analyzers: M937xA
• Required firmware: CalPod firmware for PNA or M937xA
• Required controller: 85523B CalPod Controller
