Agilent/Keysight 8560E

The Agilent/Keysight 8560E is a portable RF spectrum analyzer delivering precision signal analysis across 30 Hz to 2.9 GHz. Synthesized tuning eliminates drift while maintaining measurement accuracy across demanding RF applications. Built to MIL-T-28800 rugged standards for field deployment, the instrument combines exceptional sensitivity (–144 dBm at 1 GHz with 1 Hz RBW), wide dynamic range (100 dB third-order), and precise frequency accuracy (±135 Hz at 1 GHz after 15-minute warmup). Resolution bandwidths span 1 Hz to 1 MHz with ±10% accuracy from 1 Hz to 300 kHz. Video bandwidth ranges 1 Hz to 3 MHz. Phase noise measures –113 dBc/Hz at 10 kHz offset. The 100 dB on-screen calibrated amplitude display includes AMPCOR correction for cable loss and preamplifier gain compensation. RF input accepts +30 dBm average continuous power (≥10 dB attenuation) and +50 dBm peak pulse power (≥30 dB attenuation). Frequency reference aging rate is 1×10⁻⁷ per year with 1 Hz counter resolution.

– Technical Specifications

• Frequency range: 30 Hz to 2.9 GHz
• Resolution bandwidth: 1 Hz to 1 MHz (1, 3, 10, 30, 100 Hz digital steps available)
• Video bandwidth: 1 Hz to 3 MHz (1, 3, 10 sequence)
• Sensitivity: –144 dBm (1 GHz, 1 Hz RBW); noise floor –151 dBm
• Phase noise: –113 dBc/Hz (10 kHz offset)
• Dynamic range: 100 dB third-order
• Frequency accuracy: ±135 Hz @ 1 GHz (post 15-minute warmup)
• Amplitude display: 100 dB calibrated on-screen range
• RF input: Type N female, 50 Ω; +30 dBm continuous, +50 dBm peak pulse
• IF output: 310.7 MHz
• First LO output: 3.000–6.8107 GHz, +16.5 dBm ±2.0 dB
• Probe power: +15 Vdc, –12.6 Vdc, Ground (150 mA max each)

– Key Features

• Drift-free synthesized tuning
• AMPCOR amplitude correction feature
• Precision timebase with 1 Hz counter resolution
• Fast digital resolution bandwidths at critical frequencies
• MIL-T-28800 environmental ruggedness

– Interfaces

• GPIB (IEEE-488) control
• 10 MHz reference in/out (shared BNC, 50 Ω)
• Cal output (BNC female, 50 Ω)
• Video output (BNC, 50 Ω)
• External/gate trigger input (BNC female, >10 kΩ)
• Direct printer/plotter output (HP legacy support)
• Earphone output (0.2 W into 4 Ω)

– Typical Applications

• Wireless communication system testing and troubleshooting
• RF component characterization
• Signal analysis in field environments
• Frequency and modulation measurement
