Agilent/Keysight 86115D

The Keysight/Agilent 86115D is a plug-in optical module for the DCA platform family (86100C, 86100D mainframes) engineered for high-volume parallel transceiver testing and waveform analysis. It delivers precise optical signal characterization across Fibre Channel, Ethernet, and OTN standards from 8.5 Gb/s to 100 Gb/s, supporting both early-stage R&D and manufacturing test environments.

– Technical Specifications

Optical Channel

• Bandwidth: 20 GHz unfiltered (standard); 34 GHz (Option 282)
• Wavelength range: 750 nm to 1630 nm / 1650 nm
• Fiber support: 62.5/125 µm multimode and single-mode
• Unamplified optical receivers

Data Rates & Reference Receivers

• Standard rates: 8.5 Gb/s (8X FC), 9.953 Gb/s (OC-192/STM-64), 10.3125 Gb/s (10GbE), 10.52 Gb/s (10X FC), 14.025 Gb/s (16X FC)
• Option 282 rates: 25.78 Gb/s (100GbE), 29.75 Gb/s (OTU4), 28.05 Gb/s (32X FC)
• Hardware reference receivers: standard module supports 8.5 to 14.025 Gb/s; Option 281/282 extends to 25.78, 27.95, and 28.05 Gb/s
• Option IRC enables arbitrary rate reference receivers from 40 Gb/s (PRBS16 and shorter patterns)
• Complementary 15 Gb/s filter included when 14.025 Gb/s filter not selected

Electrical Channel

• Bandwidth: 25 GHz and 50 GHz (user selectable) for receiver testing

Noise Performance (Typical RMS)

• 5 µW at 10 Gb/s
• 8 µW at 16X FC
• 12 µW at 25 Gb/s
• Wavelength-specific noise: 8/6/6 µW (850/1310/1550 nm, 14.025 Gb/s filter); 17/13/15 µW (850/1330/1550 nm, 25.781 Gb/s filter); 18/15/17 µW (850/1330/1550 nm, 28.05 Gb/s filter); 25/18/21 µW (850/1330/1550 nm, unfiltered)

Port Configuration

• Standard: two optical channels
• Option 004: four optical ports with integrated optical switches for sequential multi-transmitter acquisition (20 GHz ports only)

– Key Features

• Dual or quad optical channel configurations
• Low-insertion-loss optical switching for parallel testing
• Modular architecture supports mixed data rates in single test session
• Hardware and software reference receivers for compliance verification

– Typical Applications

• 8X to 32X Fibre Channel transceiver validation
• 10 GbE and 100 GbE receiver compliance testing
• OC-192/OTU4 signal analysis
• High-volume manufacturing characterization
• Multi-wavelength (850/1310/1550 nm) optical performance assessment

– Compatibility & Integration

Plug-in module for Keysight DCA mainframes 86100C and 86100D.
