The Agilent/Keysight 86200B is a scalar RF detector engineered for broadband measurements across the 10 MHz to 1300 MHz band. Operating at 50-ohm impedance, this external detector integrates with Agilent/Keysight 8712 and 8714 Series network analyzers, extending measurement capability up to 3 GHz. The unit ships with a detachable 2-meter cable terminated in Type-N male connectors, allowing placement up to two meters distant from the host analyzer. Beyond traditional scalar detection, the 86200B supports advanced group delay characterization in frequency-translating devices when paired with a power splitter for AM delay measurements.
– Technical Specifications
• RF Impedance: 50 ohms
• Frequency Range: 10 MHz to 1300 MHz (extendable to 3 GHz)
• RF Connector: Type-N male
• Cable: 2-meter detachable, Type-N terminated
– Key Features
• Scalar detection across broadband RF spectrum
• Remote operation up to 2 meters from network analyzer
• Type-N male RF interface for standard laboratory connectivity
• Power splitter compatibility for group delay applications
– Typical Applications
• Scalar network analysis on 8712/8714 series platforms
• Broadband RF power and magnitude measurement
• Group delay characterization in frequency-conversion circuits via AM delay configuration
– Compatibility & Integration
Designed as an external measurement accessory for Agilent/Keysight 8712 Series and 8714 Series network analyzers. Type-N male connectors ensure standard RF connectivity.
