The Agilent/Keysight 8671A is a microwave synthesizer generator delivering precise, stable signal generation across 2.0 to 6.2 GHz. Built for demanding test applications including LO injection, radar testing, satellite communications, and component characterization, it combines 1 kHz frequency resolution with exceptional spectral purity and low phase noise.
– Technical Specifications
Frequency Performance
• Frequency range: 2.0 GHz to 6.2 GHz
• Frequency steps: 1 kHz increments
• Output power (unleveled): Minimum +8 dBm (specified +15 to +35°C)
• Flatness: < 6 dB total variation across full band
• Harmonic content: 80 dB ON/OFF ratio; 70 dB below carrier
• Non-harmonically related spurious: < -60 dBc (10 MHz–1.999999 GHz)
• Excellent phase noise and spectral purity
Time Base & Stability
• 10 MHz time base aging: < 5 × 10⁻¹⁰/day
– Key Features
• HP-IB programmable for remote control of all functions except line switches and meter mode
• Unleveled output architecture—no automatic amplitude leveling
• Operating temperature: 0 to +55°C; calibrated performance +15 to +35°C
• Compact form factor: 222 mm (H) × 425 mm (W) × 620 mm (D); 24 kg net
– Typical Applications
• Local oscillator (LO) generation for microwave receivers
• Radar system testing and characterization
• Satellite communications signal simulation
• Microwave component testing and measurement
– Compatibility & Integration
The 8671A operates identically to the 8672A across the overlapping 2.0–6.2 GHz range. For applications requiring leveled output or extended frequency coverage, the 8671B and 8672A models are available alternatives.
