Agilent / Keysight 87511B S-Parameter Test Set, 100 kHz to 500 MHz

The Agilent/Keysight 87511B S-Parameter Test Set is a specialized instrument for RF component characterization across 100 kHz to 500 MHz. This test set measures scattering parameters of one-port and two-port devices—filters, amplifiers, and related RF components—with precision directivity and port match performance. It quantifies signal reflection and transmission coefficients, enabling impedance matching validation and device performance analysis. The 87511B integrates with the Agilent 8751A Network Analyzer in both benchtop and rack-mount configurations.

– Technical Specifications

Frequency & Impedance
• Frequency Range: 100 kHz to 500 MHz
• Nominal Impedance: 75 Ohms
• Test Ports: 75 Ohm Type-N (female) connectors

Performance Characteristics
• Directivity (Port 1 & 2): >30 dB (100 kHz–300 kHz), >40 dB (300 kHz–200 MHz), >35 dB (200 MHz–500 MHz)
• Port Match (R, A, B, RF IN): >20 dB
• Source Match: >15 dB (100 kHz–300 kHz), >20 dB (300 kHz–500 MHz)
• Effective Source Match (Port 1 & 2): 15 dB (100 kHz–300 kHz), 20 dB (300 kHz–500 MHz)
• Switch Repeatability: ±0.03 dB

Environmental
• Operating Temperature: 0 °C to +55 °C
• Operating Humidity: 5% to 95% at 40 °C (non-condensing)
• Operating Altitude: Up to 4,500 meters
• Storage Temperature: -40 °C to +70 °C
• Storage Humidity: Up to 90% at +65 °C (non-condensing)
• Storage Altitude: Up to 15,240 meters

– Key Features

• Two-port device measurement with precise directivity across full frequency range
• 75 Ohm system impedance with Type-N test port connectivity
• Switch repeatability within ±0.03 dB for consistent calibration
• Source match performance optimized for low-frequency and microwave bands

– Typical Applications

• Filter and amplifier S-parameter characterization
• Impedance matching validation and network analysis
• Reflection coefficient (S11, S22) measurement for component validation

– Compatibility & Integration

Designed for operation with the Agilent 8751A Network Analyzer. Rack mount kit available as an option for 19-inch equipment rack integration.
