Agilent/Keysight AC6804B

The Keysight AC6804B is a 4 kVA AC/DC power source engineered for comprehensive testing of electronic equipment across variable power conditions. It delivers stable AC output to 310 Vrms at 20 A, or DC output to 438 V at 16 A, with programmable control over voltage, frequency, and current. The instrument operates from standard single-phase mains (100–240 Vrms, 50/60 Hz) and accommodates load power factors from 0 to 1 in either leading or lagging configuration. Front-panel operation and remote control via LAN/LXI, USB, or optional GPIB interfaces enable flexible test automation and monitoring.

– Technical Specifications

AC Output
• Maximum power: 4000 VA
• Voltage ranges: 155 Vrms (low) / 310 Vrms (high)
• Current: 40 A (low range) / 20 A (high range)
• Frequency: 40 Hz to 500 Hz
• Voltage setting accuracy: 0.3% of full scale (low) / 0.25% of full scale (high)
• Load power factor: 0 to 1 (leading or lagging)

DC Output
• Voltage ranges: 219 V (low) / 438 V (high)
• Current: 32 A (low range) / 16 A (high range)
• Power capacity: 3.2 kW

Input Requirements
• Nominal voltage: 100–120 Vrms / 200–240 Vrms, 50/60 Hz, single-phase
• Input voltage range: 90–132 Vrms / 180–264 Vrms (auto-detected)
• Input frequency: 47 Hz to 63 Hz
• Apparent power draw: ≤6400 VA
• Input current: 32 A / 16 A (@100 V / 200 V) or 53.6 A / 28.0 A (@120 V / 230 V)

Measurements
Voltage, current, and power measurements in AC, DC, and AC+DC modes.

– Key Features

• Dual output mode: simultaneous AC and DC simulation with independent control
• Wide frequency range (40–500 Hz) for global power condition emulation
• Voltage setting accuracy to 0.25% supports strict compliance testing
• Built-in web server for browser-based remote monitoring and control
• M6 terminal blocks for input and output connections

– Typical Applications

• Simulating global AC power standards and varying frequency scenarios
• Testing equipment across multiple voltage and frequency combinations
• Power factor correction and load behavior characterization
• Product safety and compliance validation under diverse power conditions

– Compatibility & Integration

• LAN/LXI Core and USB standard
• GPIB optional
• Operating temperature: 0–40 °C (non-condensing)
• Installation Category II, Pollution Degree 2, indoor industrial use
• Dimensions: 428 × 262 × 611 mm; Weight: 31 kg
