Agilent/Keysight BT2180A

The Keysight BT2180A is a breakout board that interfaces the BT2152B Self-Discharge Analyzer with battery cells under test. It provides 16 measurement channels via DB37(f) connector and two 16-pin screw terminal blocks, supporting twisted-pair wiring from 16 to 30 AWG. The board enables direct measurement of cell self-discharge current, reducing test duration from weeks or months to 1–2 hours. By rapidly sorting cells with acceptable self-discharge behavior, the BT2180A supports high-volume lithium-ion manufacturing while optimizing production costs and reducing work-in-process inventory. The board mounts via feet or four standoff holes for integration into test fixtures or cabinets.

– Technical Specifications

• Connector Interface: DB37(f) to screw terminals
• Measurement Channels: 16 per BT2180A board
• Terminal Configuration: Two 16-pin screw terminal blocks
• Supported Wire Gauge: 16 to 30 AWG twisted pair
• Cable Requirements: Twisted pairs per channel with separate braided shield around bundle; DB37(m) connectors with machined pins recommended for optimal measurement consistency with BT2152B
• Mounting: Table feet and four mounting holes for standoff attachment

– Key Features

• Direct self-discharge current measurement at the cell level
• Twisted-pair wiring support for signal integrity across extended cable runs
• Screw terminal interface for straightforward cell fixture integration
• Rapid cell binning to identify acceptable versus marginal self-discharge performance
• Accelerated test cycles enabling production throughput optimization

– Typical Applications

• Lithium-ion cell acceptance testing in manufacturing environments
• Production cell sorting and quality screening
• Cell pre-characterization prior to pack assembly

– Compatibility & Integration

The BT2180A operates with the Keysight BT2152B Self-Discharge Analyzer and BT2155A Self-Discharge Analysis Software to form a complete cell evaluation platform. Conforms to US and Canadian safety regulations; CE-marked and compliant with the European Low Voltage Directive.
