The Keysight CX1205A is a sensor head adapter that extends the current measurement capabilities of the CX3300 series Device Current Waveform Analyzer. This test lead adapter connects directly to DUT test points via two mini-jack terminals linked to the analyzer’s ammeter channels through an integrated current sensor. The included five test leads facilitate convenient connection to mini-plug test points on the device under test or its associated test board, enabling direct current measurement across a wide dynamic range.
– Technical Specifications
• Current measurement range: 40 nA to 1 A
• Resolution: 14/16-bit (via connected CX3300 series analyzer)
• Connectivity: Two mini-jack terminals for ammeter positive and negative connections
• Included accessories: Five test leads
• Bandwidth: Maximum bandwidth limited compared to SMA-type sensor heads
– Key Features
• Direct current measurement from low-level nanoampere to high-level ampere ranges
• Dedicated sensor head design for precise low-level current waveform visualization
• Mini-jack terminal interface for reliable ammeter connections
• Five integrated test leads for flexible DUT connection options
• Optimized for integration with Keysight current sensor modules
– Typical Applications
• Device power consumption profiling and analysis
• Low-level current transient capture during device operation
• Power delivery network validation
• Battery-powered device current characterization
• Embedded system current waveform analysis
– Compatibility & Integration
The CX1205A operates as a dedicated accessory within the Keysight CX3300 series Device Current Waveform Analyzer ecosystem. It integrates with associated current sensors including the CX1101A and CX1102A, leveraging the analyzer’s 14/16-bit measurement resolution for extended dynamic range current analysis. The adapter functions as the interface between DUT test points and the analyzer’s ammeter input channels.
