Agilent / Keysight DSO3062A Oscilloscope, 60 MHz

The Agilent/Keysight DSO3062A is a 60 MHz, 2-channel digital storage oscilloscope engineered for signal capture, waveform analysis, and troubleshooting across electronics testing, education, and research environments. This instrument combines a 5.7-inch QVGA color display with 1 GSa/s real-time sampling and 4 kpts memory depth to deliver fast, accurate measurements. The 8-bit vertical resolution and ±3.0% to ±4.0% DC gain accuracy (depending on range) support precise signal characterization. A built-in 5-digit hardware frequency counter and 20 automatic measurements accelerate routine diagnostics, while advanced triggering modes—edge, pulse width, and line-selectable video—isolate critical signal events. Four math functions including FFT enable frequency-domain analysis without external software.

– Technical Specifications

• Bandwidth: 60 MHz
• Channels: 2
• Sample Rate: 1 GSa/s (real-time and equivalent-time sampling)
• Memory Depth: 4 kpts
• Vertical Resolution: 8 bits
• Display: 5.7-inch QVGA color LCD, 320 × 240 resolution
• DC Vertical Gain Accuracy: ±4.0% full scale (2–5 mV/div); ±3.0% full scale (10 mV/div–5 V/div)
• Calculated Rise Time: 5.83 ns
• Frequency Counter: 5-digit hardware counter
• Power Requirements: 100–240 VAC, 47–440 Hz, automatic selection

– Key Features

• Advanced triggering: edge, pulse width, line-selectable video
• 20 automatic measurements and 4 math functions (FFT included)
• Acquisition modes: Normal, Average, Peak Detect
• Mask testing and delayed sweep for protocol and timing analysis
• Digital filtering and sequence mode acquisition
• Auto-scale feature optimizes vertical, horizontal, and trigger settings
• Internal storage: 10 waveforms and 10 setups
• USB device port (with included Scope Connect software) and USB host port for exporting setups, waveforms, and data files

– Typical Applications

Signal integrity verification, circuit debugging, educational laboratory work, and general-purpose analog waveform characterization in low-frequency domains up to 60 MHz.

– Compatibility & Integration

Standard 150 MHz passive probe (N2862A) included. Optional GPIB and RS-232 connectivity via N2861A I/O module. Rack mount kit (N2864A) available. Compatible with N2863A (300 MHz), 1141A (200 MHz differential), and N2772A (600 V CAT III, 20 MHz differential) probes.
