The Keysight DSOV134A Infiniium V-Series Oscilloscope is a 13 GHz analog bandwidth instrument designed for high-speed signal characterization and debug in advanced B2B environments. Built for engineers developing high-speed digital designs, wireless communications systems, and semiconductor test solutions, this four-channel oscilloscope delivers the measurement accuracy and analysis depth required for complex signal integrity validation.
– Technical Specifications
• Analog Bandwidth: 13 GHz (upgradable)
• Sample Rate: Up to 80 GSa/s
• Acquisition Memory: Up to 2 Gpts
• Analog Channels: 4
• Vertical Resolution: 8 bits (exceeds 12 bits with averaging)
• ENOB: Greater than 5.5
• SFDR: Exceeding 50 dBC
• Noise Floor: 1.09 mVrms at 50 mV/div
• Jitter Measurement Floor: 100 fs
• Edge Step Response: 12 ps
• Maximum Signal Integrity: Up to 33 GHz with InfiniiMax III/III+ Series probes and voltage termination adapter
• Display: 12.1-inch XGA capacitive touchscreen
• Storage: 500 GB removable solid-state drive
– Key Features
• Hardware-based real-time waveform rendering minimizes processing overhead
• Advanced serial trigger with 160-bit pattern support up to 12.5 Gb/s
• InfiniiMode enables differential, single-ended, and common-mode measurements without probe reconnection
• PrecisionProbe correction for accuracy to the probe tip
• Comprehensive voltage measurements: peak-to-peak, RMS, overshoot, preshoot, crossing point voltage, and pulse parameters
• Time-domain analysis: rise/fall time, period, frequency, pulse width
• PathWave Calibration Advisor for calibration interval tracking
• USB 3.0 connectivity with five host and device ports supporting data offload up to 200 MB/s
• AutoProbe II interface for InfiniiMax III and III+ probing systems
– Typical Applications
• High-speed digital design validation
• Wireless communications signal analysis
• Semiconductor device characterization
• Signal integrity and jitter analysis
– Compatibility & Integration
• Five USB 3.0 ports (front and rear) for host, device, and data acquisition
• Three USB 2.0 ports for standard peripherals
• AutoProbe II interface for automated probe detection and configuration
• Accessory I/O connector for digital channels on MSO variants
