The Keysight DSOX92504A Infiniium High-Performance Oscilloscope is a 25 GHz bandwidth instrument engineered for high-speed digital design, signal integrity analysis, and advanced research applications. It delivers exceptional signal fidelity with upgradeable analog bandwidth to 33 GHz, deep acquisition memory up to 2 Gpts, and measurement accuracy for complex signal characterization in demanding test environments.
– Technical Specifications
Bandwidth and Channels
• True analog bandwidth: 25 GHz, upgradeable to 33 GHz
• 4 analog channels with 25 GHz bandwidth on 2 channels; 16 GHz on 4 channels
• 16 integrated digital channels for mixed-signal analysis
Sampling and Memory
• Sample rate: 80 GSa/s (2 channels), 40 GSa/s (4 channels)
• Maximum memory depth: 2 Gpts
• Standard memory: 20 Mpts per channel
Signal Integrity Performance
• Noise floor: 1.85 mVrms at 25 GHz (50 mV/div)
• Jitter measurement floor: <100 fS
Probing System
• Probing bandwidth to 30 GHz; accessories rated to 28 GHz
• Bandwidth-upgradeable probes available
• Supports PrecisionProbe for channel characterization and compensation
Display and Interface
• 12.1-inch color touchscreen, XGA resolution
• Intuitive graphical user interface with traditional front-panel controls
– Key Features
• Advanced triggering: edge, glitch, runt, timeout, pattern/pulse range, state, pulse width, window, setup and hold, video, serial, and violation triggering
• Jitter analysis applications (EZJIT, EZJIT Plus)
• Protocol analysis support including RS-232/UART, USB, PCI Express, I²C/SPI, and CAN/LIN/FlexRay
• PrecisionProbe support for automated channel compensation
– Connectivity & Integration
• LAN: 10/100/1000 BaseT, LXI class C compliant
• USB: Four USB 2.0 host ports, one USB 2.0 device port
• Web-enabled remote connectivity
• Optional remote program interface for software automation
