Agilent / Keysight E1313A 32-Channel Scanning A/D Converter

The Agilent/Keysight E1313A is a B-size VXI module delivering 32-channel differential scanning analog-to-digital conversion for high-performance data acquisition and computer-aided test applications. With 16-bit resolution, 0.01% accuracy, and a 100 kSamples/s maximum reading rate, this register-based module integrates a 32-channel FET multiplexer and 64 kSa dual-ported FIFO buffer for efficient block transfers. Option 001 expansion adds a second identical module for 64-channel operation. The E1313A accepts 4 mV to 16 V full-scale input and supports optional Signal Conditioning Plug-ons (SCPs) for buffering, filtering, amplification, and specialized measurements including strain gauge and temperature conditioning. Automatic self-calibration and VXIbus integration make this module suitable for demanding multichannel acquisition tasks. The Keysight E1413C offers functionally identical 64-channel performance in a single C-size slot as an alternative platform.

– Technical Specifications

• Module Type: B-size, 3-slot VXIbus register-based module
• Channels: 32 differential scanning (expandable to 64 with Option 001)
• A/D Resolution: 16-bit including sign
• Conversion Speed: 100 kHz, 100 kSamples/s maximum (divided by active channel count)
• Accuracy: 0.01% of reading
• Input Range: 4 mV to 16 V full-scale
• Memory: 64 kSa dual-ported FIFO plus current value buffer
• Multiplexer: 32-channel differential FET
• Dimensions: 12 × 10 × 8 in
• Weight: Approximately 10 lbs

– Key Features

• High-density 32-channel architecture with field-expandable design
• Integrated dual-ported FIFO for efficient data streaming
• Automatic self-calibration for drift compensation
• Optional Signal Conditioning Plug-ons for DC, temperature, resistance, and strain measurements
• Register-based VXIbus control via standard command interface

– Typical Applications

• Computer-aided testing (CAT) and high-speed data logging
• Multichannel voltage acquisition and monitoring
• Temperature and resistance measurement systems
• Strain gauge analysis with bridge excitation

– Compatibility & Integration

Designed for VXIbus systems. Keysight E1413C provides functionally equivalent 64-channel, single-slot C-size alternative. Instrument drivers available from Keysight.
