The Agilent/Keysight E3615A is a 60 W single-output DC power supply engineered for benchtop and system-level electronic testing. It delivers 0–20 V at 0–3 A with exceptional line regulation, load regulation below 0.01% + 2 mV, and sub-millivolt ripple, making it suitable for development and characterization work requiring stable, low-noise power delivery.
– Technical Specifications
Electrical Performance
• Output voltage: 0–20 V
• Output current: 0–3 A
• Maximum power: 60 W
• Line regulation (CV mode): < 0.01% + 2 mV
• Line regulation (CC mode): < 0.01% + 250 µA
• Load regulation: < 0.01% + 2 mV
• Ripple and noise (20 Hz–20 MHz): < 200 µV rms, < 1 mV peak-to-peak
• Transient response: < 50 µsec recovery to within 15 mV for full-load to half-load transitions
• Operating temperature: 0–40°C at full rated output; current derated 1% per °C from 40–55°C
Display and Control
• Digital panel meters for simultaneous voltage and current display
• Voltage resolution: 10 mV (0–20 V range)
• Current resolution: 10 mA
• 10-turn potentiometers for precise voltage and current adjustment
• Remote analog voltage programming capability
Protection and Sensing
• Overvoltage protection, adjustable from front panel, disables output when threshold is exceeded
• Remote sensing automatically compensates for load-lead voltage drop
• Programming inputs protected to ±40 V
Physical Specifications
• Net weight: 12.1 lbs / 5.5 kg
• Convection cooling
• Front and rear output terminals
– Key Features
• Tight regulation and minimal output noise enable sensitive device characterization
• Dual-terminal configuration supports both benchtop and rack-mounted measurement setups
• Auto-parallel, auto-series, and auto-tracking capability for multi-unit configurations
• Fast transient response suited to dynamic load conditions
– Typical Applications
• Component and circuit testing and validation
• Prototype power delivery during development
• Educational laboratory benchtop use
Product Status: Obsolete as of January 1, 2019.
