Agilent/Keysight E4416A

The Agilent/Keysight E4416A is a single-channel EPM-P series power meter delivering high-performance RF and microwave power measurements from 9 kHz to 110 GHz. This instrument measures peak power, peak-to-average ratio, average power, and time-gated power across predefined wireless formats including GSM, EDGE, NADC, iDEN, Bluetooth, IS-95 CDMA, W-CDMA, and cdma2000. With a 20 M samples per second sampling rate and measurement speeds up to 1,000 corrected readings per second via GPIB, the E4416A delivers fast, reliable results for manufacturing, R&D, and field service applications.

The meter spans a power measurement range of −70 dBm to +44 dBm (100 pW to 25 W), with selectable resolution from 1.0 dB down to 0.001 dB in logarithmic mode, or 1 to 4 significant digits in linear mode. Video bandwidth can be adjusted to High, Medium, Low, or OFF to optimize dynamic range for peak power measurements. Three measurement speed modes—normal, x2, and fast—provide flexibility for different test scenarios.

– Technical Specifications

• Frequency range: 9 kHz to 110 GHz (sensor dependent)
• Power measurement range: −70 dBm to +44 dBm (100 pW to 25 W) (sensor dependent)
• Measurement resolution: 1.0, 0.1, 0.01, 0.001 dB logarithmic; 1–4 significant digits linear
• Sampling rate: 20 M samples per second
• GPIB measurement speed: Up to 1,000 corrected readings per second
• Power requirements: 85–264 Vac, 47–440 Hz (automatic selection)

– Key Features

• Peak, average, peak-to-average ratio, and time-gated power measurements
• Predefined configurations for 8 wireless communication formats
• External trigger input with adjustable threshold (rising or falling edge)
• TTL output and input for external device synchronization
• Adjustable video bandwidth (High, Medium, Low, OFF)
• Standard GPIB (IEEE 488.2, IEC-625) and RS-232/422 serial interfaces
• Front panel sensor and reference calibrator connections
• Compact form factor: 89 mm H × 213 mm W × 348 mm D; 9 lb

– Typical Applications

Manufacturing test, research and development, field service, and characterization of pulsed and modulated RF signals across legacy and modern wireless standards.

– Compatibility & Integration

Operable with E-series E9320 family power sensors. Includes 5 ft (1.5 m) power sensor cable; 10 ft (3 m) and 31 ft (10 m) cables available optionally. Standard line fuse: 250 V, 3.15 A, 20 mm fast blow (Keysight part 2110-0957).
