Agilent/Keysight E4838A

The Agilent/Keysight E4838A is a data generator front-end module for parallel bit error ratio testing in high-speed digital systems. Operating as a plug-in card within the E4832A carrier module, it generates and outputs differential data patterns across a 333 Kb/s to 675 Mb/s range. The module supports pseudo-random word sequences (PRWS), standard PRBS patterns up to 2^31-1, and memory-based patterns up to 2 Mb, with variable transition times between 0.5 and 4.5 ns and typical jitter below 80 ps in data mode. Signal output is configurable between RZ and NRZ formats with amplitudes from 0.1 to 3.5 Vpp, enabling testing of serializer/deserializer (SerDes), multiplexer/demultiplexer architectures, and parallel-to-serial conversion circuits across telecommunications and storage networking applications.

– Technical Specifications

• Data Rate Range: 333 Kb/s to 675 Mb/s
• Output Type: Differential, single channel
• Output Amplitude: 0.1 to 3.5 Vpp
• Transition Time (10%-90%): 0.5 to 4.5 ns variable
• Jitter (Data Mode): <100 ps pp (80 ps typical)
• Jitter (Clock Mode): 8 ps rms typical
• Signal Format: RZ/NRZ selectable
• Pattern Types: PRWS, standard PRBS up to 2^31-1, memory patterns to 2 Mb
• Weight: 2 lbs

– Key Features

• Differential output architecture with selectable RZ/NRZ encoding
• Fine-grain amplitude control spanning 0.1 to 3.5 Vpp
• Adjustable edge rates from 0.5 to 4.5 ns transition time
• Low clock jitter at 8 ps rms typical for precision timing applications
• Memory-based pattern storage enabling custom test sequences up to 2 Mb

– Typical Applications

• Gigabit Ethernet and OC-192 parallel interface testing
• SerDes and Mux/Demux device characterization
• Telecom and storage area network (SAN) IC validation
• 10GbE and forward error correction (FEC) device testing
• Transmitter and receiver manufacturing test
• IC-tester high-speed channel extension

– Compatibility & Integration

• Requires Keysight Agilent HP E4832A carrier module (one VXI slot)
• Supports up to four E4838A generator cards per E4832A module
• Part of Keysight ParBERT 81250 platform
• End-of-life status: Last order date December 31, 2016
