The Agilent/Keysight E5100B is a high-performance network analyzer designed for precise characterization of electronic components, filters, and transmission networks across DC to microwave frequencies. It delivers rapid measurement speed, exceptional dynamic range, and flexible sweep capabilities—making it essential for R&D, manufacturing, and quality assurance environments where component validation and network characterization demand accuracy and speed.
– Technical Specifications
Frequency Range
• 10 kHz to 300 MHz (standard)
• 180 MHz variant available for lower frequency applications
Measurement Parameters
• Gain (amplitude ratio), phase, group-delay, amplitude, gain-phase, and gain-delay
• S-parameters and impedance measurement
• Transmission characteristics
• Optimized resonator and filter evaluation with waveform analysis and optional phase tracking
Performance
• Measurement speed: 0.04 ms/point (IFBW = 30 kHz, ramp-sweep)
• Dynamic range: >120 dB (IFBW = 1 kHz)
• Dynamic accuracy: ±0.05 dB, ±0.3 degrees
• IF bandwidth: 10 Hz to 30 kHz in 1, 1.5, 2, 3, 4, 5, and 8 step increments
• Sweep modes: Ramp and step sweep
• Built-in source resolution: 1 mHz
RF Output Power
• Standard: −9 dBm to +11 dBm
• Optional extended range: −48 dBm to +22 dBm
• Resolution: 0.1 dB
Input Impedance
• 50 Ω (standard)
• 50 Ω / 1 MΩ selectable with 30 pF (optional)
Display & Interface
• 6.5-inch color LCD
• VGA-compatible external display output
• GPIB remote control and programming support
• Embedded HP Instrument BASIC (IBASIC) for automation
• PC-compatible DIN keyboard interface
Physical
• Compact depth: 425 mm
• Weight: ~12 kg
• Floppy disk drive and internal non-volatile memory
– Key Features
• Dual-port RF connectivity with Type-N and optional e-N selectable connectors
• Optional evaporation monitoring function for specialized manufacturing processes
• Phase tracking enhancement for precision filter and resonator testing
– Typical Applications
• Component impedance and S-parameter characterization
• Filter and resonator optimization and validation
• Transmission line and network analysis
• Manufacturing quality assurance and incoming component inspection
– Compatibility & Integration
The E5100B integrates with dedicated S-parameter test sets and the E5090A 2-port transmission/reflection test kit (compatible with E5100A/B, DC to 2 GHz).
