The Keysight E6953A is a V2X (Vehicle-to-Everything) test solution engineered for 802.11p, DSRC, and ITS-G5 standards validation. This compact, integrated PXIe system operates as a fully configurable, real-time On-Board Unit (OBU) or Road-Side Unit (RSU), delivering comprehensive RF measurements and protocol testing across all OmniAir certification test cases. The system is validated as Qualified Test Equipment (QTE) by OmniAir.
– Technical Specifications
• Form Factor: Benchtop PXIe system (1 slot)
• Frequency Band: 5.9 GHz DSRC operation
• RF Coverage: 60 MHz to 3.8 GHz or 6 GHz with modulation and analysis bandwidths up to 160 MHz
• Standards Support: IEEE 802.11p, IEEE 1609.2, IEEE 1609.3, IEEE 1609.4, SAE J2945/1
• Power Input: Auto-ranging line voltage; use Keysight-supplied power cord or equivalent
• Operating System: Tested with Windows 8
– Key Features
• PXIe Vector Transceiver Instrument (M9421A) for RF signal generation and analysis
• PXIe V2X Transceiver card (E6953-35200) providing MAC Layer analysis for IEEE 802.11p and all protocol standards
• PXI Switch card (M9155C) enabling automated testing across all supported standards
• Keysight Test Automation Platform (TAP) with V2X Framework, qualified COC test case libraries, and protocol-specific plugins
• Single integrated frame covers complete OmniAir certification test suite
• KeysightV2XReportGenerator tool for documentation and data reporting
– Typical Applications
• OmniAir DSRC certification testing
• IEEE 802.11p PHY and MAC layer validation
• V2X protocol stack verification across IEEE 1609 and SAE J2945/1 standards
• Road-Side Unit (RSU) and On-Board Unit (OBU) functional testing
• Automated manufacturing test and certification workflows
– Compatibility & Integration
Designed as an expandable platform supporting future V2X test requirements. Software prerequisites may include M9421A VXT PXIe Vector Transceiver Instrument software updates.
